Automatic PCB Soldering Robot with 3 Axis Spot Welder with Various of Welding Way

Specification:

Details:

1. Multiaxis linkage robot, using precise stepping motor, improve position precision and repeatability
precision, achieve accurate positioning of any spot 3D space

2. Using industrial control computer with embedded system, single welding, single welding, circle tin
soldering is selectable

3. Simple programing, welding point coordinates could be input derectly or be robot teached. Teaching
programming is easy and simple, no robot programming technical knowledge requirement,newer could
easy to learn operation. Easy operating teaching box, it guides welding head to reach any 3D
welding point, no specail requirement on operator's technology, achieve humanitarian programming

4. Various of welding way, support spot welding and drag welding, all parameters is setted up by user,
meet high difficult welding and micro soldering requirements. All soldering parameters could be
read and saved together with welding point coordinates, achieve flexible soldering

5. Welding set arbitrary angle & direction is available, R axis controlled welding set,could be
rotated 360 degrees freely.Setting feeding times, pre-heating time, and welding time according to
different pads and parts, achieve complex soldering with a variety of soldering points

6. Realizes real-time peripheral devices by 1/0 USB, has error alarm and high speed motion program
functions. Intelligent main control program realizes automation and intelligence

Feature:

● Temperature rising speed could be adjustable for different products

● Long life time thermode made of titanium alloy, ensure even

temperature, fast raising

● Thermode designed to be horizontal adjustment, ensure even

component compression

● Numerical control temperature, clear and precise

● Has digital manometes, preset pressure range

● Small size

● Controlled by precise PID, phasc-angle driving

● Less vibration,less noise,voltage does not fluctuate

● Welding head made of molybdenum alloys, good heat transfer
coefficient, abrasion - resistant
