high flow Ss single stage argon gas regulator with two gauges
high flow Ss single stage argon gas regulator with two gauges
high flow Ss single stage argon gas regulator with two gauges
high flow Ss single stage argon gas regulator with two gauges
high flow Ss single stage argon gas regulator with two gauges
high flow Ss single stage argon gas regulator with two gauges
high flow Ss single stage argon gas regulator with two gauges
high flow Ss single stage argon gas regulator with two gauges
Specifications
Place of Origin :
Guangdong, China (Mainland)
Brand Name :
AFK
Model Number :
R13
Supply Ability :
30000 Set/Sets per Week
Packaging Details :
Export packing
MOQ :
1 - 9 Pieces
Price :
Negotiable
Certification :
CE
MOQ :
1
Material :
316L, brass
Feature :
S
Applicable gas :
pure gas, standard gas, Corrosive gas
Maximum Inlet Pressure :
500,1500psig
Outlet pressure :
0~15, 0~25, 0~75,0~125PSIG
inlet connection :
1/4NPT M, 1/4NPT F, CGA320, CGA330, CGA350, CGA580, CGA590, CGA660
outlet connection :
6mm O.D., 10mm O.D., 1/4NPT F, 1/4NPT M.
warranty :
1year
Port :
Shenzhen
Description

high flow Ss single stage argon gas regulator with two gauges

Technical Parameter:

Maximum Inlet Pressure 500,1500psig
Outlet Pressure Ranges 0~15, 0~25, 0~75,0~125PSIG
Safety test pressure 1.5 times maximum inlet pressure
Operating Temperature -40°F to +165°F / -40°c to 74°c
Leakage Rate Against Atmosphere 2*10-8atm cc/sec he
Cv value 1.8

Material:

Body 316L, Brass
Bonnet 316L. Brass
Diafragm 316L
Strainer 316L(10 μm)
Seat PCTFE,PTEE
Spring 316L
Plunger valve core 316L

Design Feature:

Single-stage pressure reducer

Maternal and diaphragm use hard seal form

Body NPT:inlet and outlet interface 3/4''NPT(F)

pressure gauge:relief valve interface 1/4'' NPT(F)

The internal structure easy to purge

Can set filters

Can use a panel or wall mounting

Typical Applications:

Labotary

Gas Chromatography

Gas laser

Gas bus-bar

petro-chemical industry

Test equipment

Flow Diagram:

high flow Ss single stage argon gas regulator with two gauges

Ordering Information

R13 L B E H G 04 04 P
Item

Body

Materia

Body

hole

Inlet

pressure

 Outlet pressure Pressure gauge Inlet size Outlet size Options
R13 L:316 A E:1500psi H:0~125psig G:MPa gauge 04:1/2”NPT(F) 04:1/2”NPT(F) P:Panel mounting
B:Brass B F:500psi J:0~75psig P:Psig/bar gauge 05:1/2”NPT(M) 05:1/2”NPT(M) R:With relief valve
D L:0~25psig W:No gauge 06:3/4”NPT(F) 06:3/4”NPT(F)
G M:0~15psig 13:1/2”OD 13:1/2”OD
J 14:3/4”OD 14:3/4”OD
M Other type is available Other type is available

Product details:

high flow Ss single stage argon gas regulator with two gauges

high flow Ss single stage argon gas regulator with two gauges

high flow Ss single stage argon gas regulator with two gauges

high flow Ss single stage argon gas regulator with two gauges

FAQ

Q. Are you manufacturer?

A. Yes, we are manufacturer.

Q.What is lead time?

A.3-5days. 7-10 days for 100pcs

Q. How do I order?

A.You can order it from Alibaba directly or send us a inquiry. We will reply you within 24 hours

Q. Do you have any certificates?

A. We have CE certificate.

Q. What materials do you have?

A. aluminium alloy and chrome plated brass are available. The picture shown is chrome plated brass. If you need other material, pls contact us.

Q. What is maximum inlet pressure?

A.3000psi (about 206bar)

Q. How do I confirm inlet connnection for cylidner?
A. Pls check cylinder type and confirm it. Normally, it is CGA5/8 male for Chinese cylinder. Other cylidner adapter are also
available e.g CGA540, CGA870 etc.

Q. How many types for connecting cylinder?

A. Down way and side way. (you can choose it)

Q. What is product warranty?

A: The free warranty is one year from the day of Commissioning qualified.If there is any fault for our products within the free warranty period, we will repair it and change the fault assembly for free.
