Low Pressure 10bar Direct Acting 1-1/4 Brass water Solenoid Valve 24v
Low Pressure 10bar Direct Acting 1-1/4 Brass water Solenoid Valve 24v
Low Pressure 10bar Direct Acting 1-1/4 Brass water Solenoid Valve 24v
Low Pressure 10bar Direct Acting 1-1/4 Brass water Solenoid Valve 24v
Low Pressure 10bar Direct Acting 1-1/4 Brass water Solenoid Valve 24v
Low Pressure 10bar Direct Acting 1-1/4 Brass water Solenoid Valve 24v
Low Pressure 10bar Direct Acting 1-1/4 Brass water Solenoid Valve 24v
Low Pressure 10bar Direct Acting 1-1/4 Brass water Solenoid Valve 24v
Low Pressure 10bar Direct Acting 1-1/4 Brass water Solenoid Valve 24v
Low Pressure 10bar Direct Acting 1-1/4 Brass water Solenoid Valve 24v
Low Pressure 10bar Direct Acting 1-1/4 Brass water Solenoid Valve 24v
Low Pressure 10bar Direct Acting 1-1/4 Brass water Solenoid Valve 24v
Specifications
Place of Origin :
Guangdong, China (Mainland)
Brand Name :
AFK
Model Number :
2W-320-32
Supply Ability :
30000 Set/Sets per Week
Packaging Details :
White box + Export packing
MOQ :
1 - 9 Sets
Price :
Negotiable
Certification :
CE
Application :
General
Material :
Brass
Temperature of Media :
Medium Temperature
Pressure :
Low Pressure
Power :
Solenoid
Media :
Water
Port Size :
1-1/4"
Structure :
Diaphragm
Product name :
2W
Orifice size :
32mm
Working pressure :
0-10bar
Operation :
Normally closed
Applicable medium :
Water/ Gas / Oil
Seal :
NBR VITON EPDM
Body material :
Brass
Connection :
NPT thread, G thread
Type :
Direct acting
Standard or Nonstandard :
Standard
Port :
ShenZhen
Description
Low Pressure 10bar Direct Acting 1-1/4" Brass water Solenoid Valve 24v
Product Description
Model NO.
2W-025-06
2W-025-08
2W-040-10
2W-160-10
2W-160-15
Pipe size
1/8'
1/4'
3/8'
1/2'
Orifice size
2.5mm
4mm
4mm
16mm
16mm
CV value
0.23
0.6
4.8
4.8
Fluid
Air water oil , the neutral gasliquid
Service voltage
AC380V AC220V AC110V AC24V DC24V DC12V ( allow ± 10% )
Operating
Direct acting
Type
Body Material
Brass
viscosity
Working pressure
( water, air ) : 0~10 kgf/cm² ( oil ) : 0~7 kgf/m²
Material of seal
Standard : below 80℃ fluid temperature use NBR , below 120℃ use EPDM, below 150℃ use VISTON
Model NO.
2W-200-20
2W-250-25
2W-320-32
2W-400-40
2W-500-50
Pipe size
3/4'
1'
1 1/4‘’
1 1/2‘’
2‘’
Orifice size
20mm
25mm
32mm
40mm
50mm
CV value
7.6
12
24
29
48
Fluid
Air water oil, the neutral gasliquid
Servise voltage
AC380V AC220V AC110V AC24V DC24V DV12V ( allow ± 10%)
Operating
Type
Normally Closed
Body Material
viscosity
( Below )20CST
Working pressure
( water, air ) :0~10 kgf/cm² ( oil ) : 0~7 kgf/m²
Material of seal
Standard : below 80℃ fluid temperature use NBR, below 120℃ use EPDM, below 150℃ use VITON
Structure Parameters
Low Pressure 10bar Direct Acting 1-1/4
Related Products
Low Pressure 10bar Direct Acting 1-1/4

2T series 1inch Normally closed 220v ac co2 solenoid valve

*Size: 1 inch
*Medium: Gas
*Operating: Pilot
*Connection: G thread, NPT thread
*Type: normally closed
*Material: Stainless steel
*Working pressure: 0-6 bar
*Working voltage: AC380V, AC220V, AC110V, AC120V, *AC24V, DC24V, DC12V

Product Show
Low Pressure 10bar Direct Acting 1-1/4
Low Pressure 10bar Direct Acting 1-1/4
Low Pressure 10bar Direct Acting 1-1/4
Packing & Delivery
Low Pressure 10bar Direct Acting 1-1/4
Packaging
Size
17cm*17cm*17cm
Weight
Different size has different weight
Packaging Details
The normal package is wooden box(Size: L*W*H). Or according to customers special request.
