AC220V AC110V High Temperature Brass 3/4 Steam Solenoid Valve
AC220V AC110V High Temperature Brass 3/4 Steam Solenoid Valve
AC220V AC110V High Temperature Brass 3/4 Steam Solenoid Valve
AC220V AC110V High Temperature Brass 3/4 Steam Solenoid Valve
Specifications
Place of Origin :
Guangdong, China (Mainland)
Brand Name :
AFK
Model Number :
2L-20
Supply Ability :
30000 Set/Sets per Week
Packaging Details :
White box + Export packing
MOQ :
1 - 9 Sets
Price :
Negotiable
Payment Terms :
L/C, Western Union, MoneyGram
Application :
General
Material :
Brass
Temperature of Media :
Medium Temperature
Pressure :
Low Pressure
Power :
Solenoid
Media :
Water
Description
AC220V AC110V High Temperature Brass 3/4" Steam Solenoid Valve
DESIGN FEATURES
1. Pilot
2. Fit for Liquid gas steam
3. Normally open closed.
4.Pipe size from 1/2' to 2' .
5. Service voltage : AC380V, 220V,110V,24V DC24,12V
6.Thread connector : G
7.Large flow.
8.Material: Brass
Structure Parameters
Maximum working pressure 1.6Mpa
Operating pressure range 0.2-1.6Mpa
Media temperature <20cst liquid gas steam
Operation Pilot type
Voltage AC:380V 220V 36V/50Hz DC:24V
Isulation grade B class
The power supply range -15%~+10%
Power 26W
Response time open <=2 second close<=3 second
Install way Media flow direction and the no the arrow consistent.The coil vertically upward, the working media clean and no particle impurities

Product Show
AC220V AC110V High Temperature Brass 3/4
