Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316
Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316
Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316
Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316
Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316
Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316
Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316
Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316
Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316
Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316
Specifications
Brand Name :
AFK
Model Number :
R11
Certification :
CE
Place of Origin :
China
MOQ :
1~10
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200PC
Delivery Time :
20Day
Packaging Details :
WOODEN
After-sales service provided :
Online support
Condition :
New
Material :
Stainless Steel,316
Warranty :
1 Year
Key words :
Nitrogen Argon Ammonia Gas Pressure Regulator
inlet pressure range :
2000psi
outlet pressure range :
300psi
inlet and outlet :
1/8"NPT F
Description

Specification
1 max. inlet pressure 500,3000psi
2 outlet pressure 0~25,0~50,0~100,0~250,0~500psig
3 proof pressure 1.5times of maximum rated pressure
4 working tem -40℉~+446℉(-40℃~+230℃)
5 leakage rate 2*10-8 atm cc/sec He
6 Cv 0.08

Material
1 Body 316L,Brass
2 Roof 316L,Brass
3 Diaphragm 316L
4 Filter mesh 316L(10μm)
5 Valve seat PCTFE,PTFE,Vespel
6 Spring loaded 316L
7 Valve disc regulation pole 316L

Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316 Typical Applications
Laboratory
Gas chromeatograph
Gas laser
Gas bus
Oil and chemical industry
Tested instrumentation

R11 Series stainless steel pressure regulator steel pressure regulator is Single-stage diaphragms, vacuum structure Stainless diaphragms output. It has piston pressure reducing structure, constant outlet pressure, mainly used for high input pressure, suitable for purified gas, standard gas, corrosive etc.

Design Features
1 Single-stage reduce structure
2 Use hard-seal between body and diaphragm
3 Body thread:1/4"NPT (F)
4 Easy to sweep inside body
5 Filter mesh inside
6 Panel mountable or wall mounted

Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316

Argon Ammonia Gas Pressure Regulator 2000psi Nitrogen AFK R11 SUS316

Ordering Information

R11 L B B D G 00 02 P
Item Body Material Body Hole Inlet Pressure Outlet
Pressure		 Pressure Guage Inlet
size		 Outlet
size		 Mark
R11 L:316 A D:3000 psi F:0-500psig G:Mpa guage 00:1/4″NPT(F) 00:1/4″NPT(F) P:Panel mounting
B:Brass B E:2200 psi G:0-250psig P:Psig/Bar Guage 01:1/4″NPT(M) 01:1/4″NPT(M) R:With relief valve
D F:500 psi K:0-50pisg W:No guage 23:CGGA330 10:1/8″ OD N:Needle calve
G L:0-25psig 24:CGGA350 11:1/4″ OD D:Diaphregm valve
J 27:CGGA580 12:3/8″ OD
M 28:CGGA660 15:6mm OD
30:CGGA590 16:8mm OD
52:G5/8″-RH(F)
63:W21.8-14H(F)
64:W21.8-14LH(F)
