Specifications
Brand Name :
YHDAA
Model Number :
YHD-M802D
Certification :
CE,FCC,ROHS,IP54,FDA,SGS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Packaging Details :
YHD-M802D 2D CMOS Barcode Scanner Module
Type :
YHD-M802D 2D CMOS Barcode Scanner Module
Source :
(Aim) Green LED
Indication :
Buzzer & LED
Decoding Capability :
1D 2D QR codes
Working Voltage :
DC3.3 V
Drop test :
1.5m fall to concrete
Description

1D 2D QR Fix Mounted Barcode Scanner Automatic Trigger Fast Scanning USB RS232 TTL Scan Engine

3 kinds of output interfaces, RS232,USB,TTL,Micro USB . Meet more interface requirements,2D/QR code scanning module use CMOS Optical Imaging Scanning Technology: Which can identify screen code, incomplete code and fuzzy code etc.Effectively compensate for the problem that scanner can not identify screen code.

Features

● Mini Size: 2.1 *1.6 *1.2cm/ 0.82 *0.62 *0.47in.

● Support inserting characters at any position and character replacement.

● Small size,easily to integrate into any device, especially for limit space application.

● Powerful decoding capacity for most 1D and 2D codes,can read incomplete and fuzzy codes.

● Support multi-language output directly, such as Russian, Japanese,Traditional Chinese, Simplified,Chinese, Korean, Thai, etc.

● Support secondary development -- the serial port development instruction is complete to satisfy each kind of host computer control interactive demand.

● Application fields: parcel locker,supermarket locker, ticket machine, self-service vending machine, intelligent express cabinet, kiosk,locker, access control machine,self-service store, check-in machine, hospital,PDA,etc.

Technical parameters

Imaging Sensor : CMOS

Optical Source : (Aim) Green LED, (Illumination)white LED

Trigger Mode : Auto-sensing scanning

Indication : Buzzer & LED

Resolution : Ratio 640×480 CMOS (300,000 pixel)

Decoding Speed : 500times/second

Interface : RS232,USB,TTL,Micro USB

Resolution : 4mil

Decoding Capability : 1D: UPC/EAN,with complementary UPC/EAN,Code128,Code39,Code 39Full ASCII,Coda bar,industrial /Interleaved 2 of 5 Code93,MSI,Code11,ISBN,ISSN,China post,GS1 Databar,etc.

2D: PDF417 QR Aztec DataMatrix Maxicode MicroPDF417 etc

Depth of field : 40-100mm Code 39(5MIL),50-220mm EAN-13 (13MIL),50-90mm Data Marix(10MIL),30-150mm PDF417(6.67MIL),25-240mm QR Code(20MIL)

Scan Angle : Roll 360°, Pitch± 55°, Skew ±55°

Current Working :160mA Stand-by : 20mA

Working Voltage : DC3.3 V

Storage Temperature : -40°C ~ 70°C / -40°to 158°F

Working Temperature : -20°C ~ 60°C / -4°to 140°F

Certificate : CE,FCC,ROHS,IP54,FDA,SGS
