Product Description
PF>0.95, CRI >80Ra, THD<15%
Anti-thunder: 4KV
IK Grade: IK10
Surge Protection: 10KV
LED Junction Temperature: ≤65°C
Working Temperature: -40ºC~+50ºC
Humidity: 10%~90%RH
Lumileds 3030 SMD LED, 150lm/w
Meanwell driver, 100-277VAC, 90-305V, 180-528V also available
Optional Function: DALI, 1-10V dimmable, daylight sensor, microwave sensor
Material: Pure aluminium 1060, Optical lens, stainless screws
Ideal mounting height: 8-15 m
Simple and elegant appearance, anodized housing, durable.
Unique UFO shape, lighter and smaller, no reflector, saving much freight cost.
Wide aluminium plate + large diameter PCB, heat dissipation fast and evenly.
All stainless screws prevent bad situation.
One-piece PC lens and high-quality silicone ring for excellent airtight effect, protecting from heavy rain and dust in tunnel lighting circumstances Certification: UL, cUL, DLC, TUV, GS, CB, SAA, FCC, CE, RoHS.
Warranty: 5 years

Product Advantages:
UL Meanwell driver
Lumileds SMD 3030, 150lm/w
Non-dimmable and dimmable are the same price
Adopted hydraulic technology of Pure aluminium 1060.
Chimney structure heat dissipation, air convection effect, good thermal management system, improving heat dissipation performance to long life time.
Pure aluminium is Hydraulic technology, thermal conductivity coefficient is 220W/m. k
The performance of thermal conductivity of Pure aluminium 1060 is faster 200% than profile extruded aluminium 6063.
The performance of thermal conductivity of Pure aluminium 1060 is faster 275% times than Die-cast aluminium ADC12.
Weight is light 3.2kg, saving much freight cost and high performance cost ratio.

Installation: Loop & Hook hanging / Wall mount / Surface mount / Rack mount

Applications
1. factories, industrial production workshop, warehouse;
2. gym, stadiums, golf courses,
3. commercial establishments, overpasses, outdoor advertising board, landmarks;
4. stage, yard, garden, lawn, park, plaza;
5. supermarket, shopping mall, exhibition hall;
6. ships, airports, subways, gas station, the train station, highway toll station, dock
7. factory, office, meeting room, conference hall, storeroom, etc.

User Manual:
Switch off power of the mains supply or respectively of the connection lead before doing any works.
Assembly must not damage or destroy conducting paths.
Make sure that the product is mounted on a stable, even and tilt-fixed background.
The complete installation must be done by an electrical expert who is familiar with the valid directives.

Quaity Control:
Stability TEST: make sure 100% of the lamps be aging test at least 48hours
Lighting TEST: make sure 100% of the lamps be lighted before packing
Drop TEST: make sure every single light have been well protected by box
