Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture
Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture
Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture
Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture
Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture
Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture
Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture
Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture
Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture
Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Boente
Model Number :
BD619
Packaging Details :
Carton
MOQ :
10 Units
Price :
$25.00/Units 10-19 Units
Type :
Tabletop Socket
Grounding :
Non-Grounding
Rated Voltage :
110~220V
Rated Current :
5A
Application :
Commercial, office desk/conference table/meeting table
Style :
Desktop Socket
Material :
zinc alloy finish
Panel corner :
round or square
Panel size :
266*130*7mm
Box size :
224*109*68
Color :
silver or black
Power Outlet :
US standard Power
Data Oultet :
2*RJ45/1*VGA/1*Audio
Description

Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture

Poster

Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture

Product Catalogue
Table Hidden Connection Box / Pop Up Power Socket Box for Conference Furniture

Introduction:

Desktop Socket series offer a solution of compact & beautiful desktop signal connection. The socket could be easily and conveniently connected with the electric equipments. Tabletop Socket is designed for connection of video, audio, computer video, network, telephone and power, etc. When the mechanism is opened, kinds of electric wires and data wires could be inserted and connected into the box.

Press the top of the desktop socket, the mechanical Locking device inside the desktop power plug will be released and the connection panel will be opened smoothly by the Pneumatic Support Structure, and use the seams on the panel which user could connect Video, Audio, Network, Telephone, Power and so on. After using the hidden desktops ocket, Just press the panel cover, the Mechanical Locking Device inside the pop up desktop socket will lock the box. The locked connection box is flush with the tabletop and all the connections are hidden dexterously. The neat & elegant topside of the box together with the tabletop form an integrated mass.

Feature:

Desktop Socket by pneumatic pressure gas pole quietly

Table top of tabletop socket is mountable

The zinc alloy plate of spring up desktop power plug is 5mm

Different sockets into tabletop power outlet could be added as required

Round or Square corner of office power data outlet is available for selection

Silver or black socket of tabletop interconnect box is available

Various versions of power socket is available

Characteristic

1, high quality zinc alloy finishing panel

2, A=A strong carton with foam cushion and waterproof film

3, silver/black is available for color selection

4, Power plug and voltage could be changed accordingly.

5, OEM with logo on product and packing is available

6, Customized made with different modules is available

7, Quality of tabletop socket is approved by CE

Application:

Desktop socket is widely used on office furniture, high tier office, luxury conference table, hotel and multimedia classroom and training room.

Parameter:

Item Model

 BD619
Material zinc alloy
Panel Size 266*130*7mm
Box Size 224*106*68mm
Color silver or black
Detail Sockets 2-US standard Power, 2-Network, 1-VGA,1-USB,1-Audio

Selection Parts :

Power

Socket (Selectable )

Universal

100-240V AC,50/60HZ,5A

US version

100-240V AC,50/60HZ,5A

UK version

100-240V AC,50/60HZ,5A

Central EU version

100-240V AC,50/60HZ,5A

FR and BL version

100-240V AC,50/60HZ,5A

South Africa version

100-240V AC,50/60HZ,5A

Australia version

100-240V AC,50/60HZ,5A

Connector

(Selectable)

Computer

15 pin HD VGA female

Audio

3.5mm stereo female jack

Video

RCA female

Lan

RJ45 ( CAT5e/ CAT6) network/data

Telephone

RJ11 voice

USB

USB2.0/3.0 female

HDMI

HDMI 1.3 female

Microphone

6.5mm stereo female jack

XLR

female jack

DVI

Female jack

Switch

press switch

Working temperature

5°C ~ 45°C

Working humidity

10% ~90 %

Storage temperature

- 20 °C ~70 °C

Storage humidity

5% ~95 %

Professional Service:

1, Any of inquiries will be response within 48 hours

2, Sizable accessories of products for replacement

3, Sample of hidden desktop socket is available.

Warranty:

Study the user’s manual carefully before installation.

All of our products provide 12 months warranty! The warranty period starts from the goods receipt by initial consignee.

Payment:

T/T, L/C, Western Union, Money Gram, Crash is acceptable
