18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device
18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device
18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device
18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device
18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device
18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device
18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device
18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device
Specifications
Place of Origin :
shenzhen
Certification :
UL,ROHS
Model Number :
PIFP0005
MOQ :
500 set
Price :
usd3-5 each set
Packaging Details :
5pcs/inner box, 8 box for one carton
Delivery Time :
14Days after order confirm
Payment Terms :
TT, LC, Paypal, etc
Supply Ability :
1000Piece/days
Brand Name :
tac
type :
lifepo4 battery pack
model :
ifr18650 3ah 12.8v
capacity :
3000mah
voltage :
12.8v
circle life :
2000 times
warranty :
12 months
pcb :
involve
connector :
customized
Description

18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device

Specification for 12V Power Tool Rechargeable Batteries 3Ah For Monitoring Device

No.

Item

Rated Performance

Remark

1

Rated Capacity

Typical

3.0AH

Standard discharge(0.2C C5A) after Standard charge

Minimum

2.8AH

2

Nominal Voltage

12.8V

Mean Operation Voltage During Standard Discharge After Standard Charge

3

Voltage at end of

Discharge

10V

Discharge Cut-off Voltage

4

Charging Voltage

14.8V

7

Cell and assembly method

IFR18650EC-1.5AH

4S2P

6

Standard charge

Constant Current 0.2C5A

Constant Voltage 14.6V

0.05 C5A cut-off

Charge time : Approx 7.0h

7

Standard discharge

Constant current 0.2 C5A

end voltage 10V

8

Maximum Continuous Charge Current

4.5C5A

9

Maximum Continuous Discharge Current

7 C5A

10

Operation Temperature Range

Charge: 0~45℃

60±25%R.H.

Bare Cell

Discharge: -20~60℃

11

Storage Temperature

Range

Less than 1 year: 0~25℃

60±25%R.H.

at the shipment state

less than 3 months: -5~35℃

12

Weight

Approx 0.6KG

Bare Cell

13

Cell Dimension

High:145mm

Max Dimension

Width: 22mm

Length: 80mm
Power Tool Rechargeable Batteries of 12V 3Ah For Monitoring Device
18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device
Power Tool Rechargeable Batteries of 12V 3Ah For Electric Toys:
18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device
18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device

More high power single cell

Size Model Standard Voltage Standard Capacity Dimension with Tube Max charge rate Max discharge rate
(V) (mAh)

Diameter

(mm)

Height

(mm)

 (mA) (h)
14 Series LFP14430-400 3.2 400 14.2 43 1C 3C
LFP14430-500 3.2 500 14.2 43 1C 3C
LFP14500-500 3.2 500 49.8 49.8 1C 3C
LFP14500-600 3.2 600 14.2 45 1C 3C
18 Series LFP18500-1000 3.2 1500 18 45 1C 3C
LFP18650-1500 3.2 1500 18.5 65 1C 3C
INR18650-2000 3.7 2000 18.5 65 1C 10C
INR18650-2200 3.7 2200 18.5 65 1C 10C
INR18650-2600 3.7 2600 18.5 65 1C 10C
INR18650-2900 3.7 2900 18.5 65 1C 10C
26 Series LFP22650-2100 3.2 2100 22.5 65 1C 3C
LFP26500-2400 3.2 2400 26.5 50 1C 3C
LFP26650-3000 3.2 3000 26.5 65 1C 3C
LFP26650-3200 3.2 3200 26.5 65 1C 3C
LFP26650-3300 3.2 3400 26.5 65 1C 3C
LFP26650-3600 3.2 3600 26.5 65 1C 3C

TAC support various battery pack involve lithium-ion and lifepo4 raw material

18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device

About Tac Battery

18V Power Tool BL1830 Rechargeable Batteries 3Ah For Monitoring Device
