32650 3.2V LiFePO4 Battery Battery Pack 6.4V 5AH With BMS For Solar Power
32650 3.2V LiFePO4 Battery Battery Pack 6.4V 5AH With BMS For Solar Power
32650 3.2V LiFePO4 Battery Battery Pack 6.4V 5AH With BMS For Solar Power
32650 3.2V LiFePO4 Battery Battery Pack 6.4V 5AH With BMS For Solar Power
Specifications
Brand Name :
TAC OEM ODM
Model Number :
6.4V 5Ah
Certification :
MSDS REACH ROHS
Place of Origin :
Shenzhen zhuhai
MOQ :
200PCS
Price :
USD 40-50
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000 pack for one week
Delivery Time :
7 days for single cell 15-20 days for battery pack
Packaging Details :
Follow UN38.3 Rule
Place of Origin: :
Guang dong
Brand Name: :
TAC-PIFP0924
Model Number: :
6.4V 5Ah
Composed Type: :
IFR32650 5Ah 2S1P 6.4V
Size: :
H65:W33:L68mm
Weight: :
300g
Environmental Compliance: :
UN38.3, ICE62133, ROHS.
circle life :
2000times
Description

32650 LiFePO4 Battery Battery Pack 6.4V 5AH With BMS For Solar Power

Features for 32650 LiFePO4 Battery Battery Pack 6.4V 5AH With BMS For Solar Power

1.The highest capacity 5Ah in 32650 size ,The nominal voltage:6.4V meet most application require.

2. The accurate size for battery pack:Max H65:W33:L68mm meet your design space limit

3. Ths single cell is a level ,100% truth capacity for the energy type IFR32650 5Ah 3.2V

4. Deep circle and long cycle life over 2000 times base on DOD 80%

5. Through certification:UN38.3,ICE62133,RoHs. For single cell

6. Low self-discharge less than 3% monthly

7. Other name 32700. Actually IFR32650 and IFR32700 is same model , The size is D=32MM H=70+/-5MM , So some buyer call 32650, and some buyer call 32700

Quick Detail:

Place of Origin: Guang dong China Brand Name: TAC-PIFP0734
Model Number:

6.4V 5Ah

 Composed Type: IFR32650-5Ah 2S1P
Rated Capacity: 5Ah Weight: 300g
Size: H65:W33:L68mm Voltage: 6.4V
Cycle Life: >2000times Durability: High capacity longer time
OEM & ODM: Support Packing: PVC Packing
Warranty: 12months Environmental Compliance: UN38.3, ICE62133, ROHS.

Specifications for 32650 LiFePO4 Battery Battery Pack 6.4V 5AH With BMS For Solar Power

No.

Item

General Parameter

Remark
1

Rated Capacity

 5.0Ah

Charge: CC@0.2C to 7.3V, then CV till current to 0.02C.

Discharge: 0.2C to 5.0V
2

Minimal Rated Capacity

 4.9Ah
3

Nominal Voltage

 6.4V
4

Life Exception

 Higher than 80% of the Initial Capacity of the Cells

Charge: CC@0.2C to 7.3V, then CV till current to 0.02C

Rest: 30min.

Discharge: 0.2C to 5.0V

Temperature:20±5℃

Carry out 1200cycles 80%DOD
5

Discharge cut-off voltage

 ≥5V

5.0V( recommended)
6

Charging cut-off voltage

 ≤7.3V

7.3V (recommended)
7

Cell and assembly method

 IFR32650-5.0Ah 2S1P
8

Internal resistance

 ≤100mΩ
9

Housing material

 PVC
10

Weight

 Approx: 300g IFR32650-3.3Ah
11

Max. Dimension

 H65:W34:L68mm

Application:

1. ELectronic Toy,Laptop,Self-powered super flashlight

2. Gas meter, Water meter,Electricity meter

3. Wind power, Electrocar,Solar power,etc

4.Tracking device

External Packing for LiFePO4 Battery With BMS

1 SET battery pack protect by double deck sponge bag

3-5 bags for one inner paper box

8 boxes for one carton

32650 3.2V LiFePO4 Battery Battery Pack 6.4V 5AH With BMS For Solar Power

Delivery Time

In order to delivery the correctly cargo on time , Tac arrange the order follow below process

1. Issue the specification promptly and confirm all the detail with customer requested

2. After confirm the detail , Tac Start to prepare the bulk cell

3.TAC delivery the samples with 7-15 days for battery pack and 25-30 days for OEM order.

Similar Picture for 32650 LiFePO4 Battery Battery Pack 6.4V 5AH With BMS For Solar Power

32650 3.2V LiFePO4 Battery Battery Pack 6.4V 5AH With BMS For Solar Power

Similar Production for LIFEPO4 Battery Pack

Portable Energy Storage made by IFR26650 ,The battery pack with plastic outer shell

12V 100MAH for street light

32650 3.2V LiFePO4 Battery Battery Pack 6.4V 5AH With BMS For Solar Power

About TAC Battery Also Support 48v Battery Pack Of EV

32650 3.2V LiFePO4 Battery Battery Pack 6.4V 5AH With BMS For Solar Power
