Specifications
Place of Origin :
Shaanxi, China
Brand Name :
LEEO
Model Number :
LA-10-120
Supply Ability :
200 units/ per Month
Price :
$2000---$5000/unit
Certification :
CE
MOQ :
1-5 units
Delivery Time :
10-20 work days
Type :
Doors
Size :
Customized
Truck Model :
DONGFENG, Foton, Howo, JieFang
Application :
Van Truck
Payment Terms :
T/T
MOQ :
5 Sets
Load Rated :
1000 Kg
Warranty :
12 Months
Description

Truck Hydraulic Equipment Cantilever Tail Gate Lift Control Board 1000kg Loading

Product Description

Brand LEEO
Load Rated 1000 KG
Max Lift Height 1200 MM
Platform Material Steel or Aluminum Alloy
Platform Dimension (Width* height) 2000 * 1800 MM(also can do customized)
Platform Weight 290-400 KG(depends on material)
Operating Voltage DC12V/24V
Power 2KW
Lift Speed 60-90mm/s(adjustable)
System Pressure 18MPa

Cantilever lifts have the advantage of being able to tilt, which means they can often form a ramp arrangement, which may be more appropriate for some applications. It also means that it can be easier to load or unload on uneven ground.

Using a tail lift can make it unnecessary to use machinery such as a forklift truck to load heavy items on to a vehicle. A tail lift can also bridge the difference in height between a loading dock and the vehicle load bed.

Tail lifts are available for many sizes of vehicle, from standard vans to articulated lorries, and standard models can lift anywhere

Tail lifts make it easier to safely load and unload trucks and can improve work efficiency and save labor costs

Why Choose US

A>We are proficient in products, understand customers, put people first, and pursue excellence.

B> Our products have a high technical starting point: they are at the highest level in China.

C> Our product hydraulic system selects European well-known brands—HALDEX, PAKER.MPI to ensure quality

Main Products Parameter

Model No Load capacity (KG) Height from Ground to Carriage (MM) Platform Dimension (W*H) MM Operating Voltage (V) Lifting Speed (CM/S) Total weight (KG)
Steel Aluminum Alloy
LA-7-90 700 800-900 1600*1700 12 6-9 320 260
LA-10-120 1000 950-1200 1800*1700 12/24 6-9 390 290
LA-15-120 1500 950-1200 2000*1700 12/24 6-9 450 330
LA-15-135 1500 1050-1350 2200*1800 24 6-9 490 370
LA-15-152 1500 1150-1520 2300*1800 24 6-9 550 430
LA-20-135 2000 1050-1350 2400*1800 24 6-9 520 410
LA-20-152 2000 1150-1520 2400*1800 24 6-9 580 460
LA-25-152 2500 1150-1520 2400*1800 24 6-9 630 490
LA-25-160 2500 1150-1600 2400*1800 24 6-9 750 590

Company Profile

Xi'an Leeo Hydraulic Equipment Co., Ltd., established in August 2011, is located in the beautiful historical city - Xi'an, Shaanxi Province. It is a professional manufacturer of "truck hydraulic tailgate lift" products of high-tech private enterprises, the company gathered a number of domestic and foreign outstanding truck tailgate lift industry specialized persons, concentrate, professional, focus on truck tailgate lifts products and parts of the technology research and development, manufacturing and sales, "integrity, innovation, creating value for customers" business philosophy, To build "LEEO ® " tailgate lift high-end national brand, based on the domestic, look at the world, exhausted and domestic and foreign automobile manufacturing enterprises, logistics and transport enterprises and the community sincere cooperation and provide excellent products and the highest quality services.

Loading 1000kg Cantilever Tail Lift 60-90mm/S Hydraulic Lift Gate For Box Truck

FAQ:

Q:HOW ABOUT THE PAYMENT?

A:WE USED T/T 50% AS DEPOSIT AND BALANCE BEFORE SHIPMENT.

Q:HOW AHOUT THE DELIVERY TIME?

A:THE DELIEVERY TIME IS ABOUT 10-15 DAYS AFTER RECEIPT DEPOSITE.

Q:HOW TO DELIVERY THE GOODS.

A: BY SEA OR BY RAILWAY.

Q: HOW LONG IS THE WARRANTY TIME?

A:2000 WORKING HOURS OR 12 MONTHS,WHICHEVER COMES FIRST.
