1000Kg Loading Hydraulic Tail Lift 1.2m Truck Tail Gate Lift
1000Kg Loading Hydraulic Tail Lift 1.2m Truck Tail Gate Lift
1000Kg Loading Hydraulic Tail Lift 1.2m Truck Tail Gate Lift
1000Kg Loading Hydraulic Tail Lift 1.2m Truck Tail Gate Lift
Specifications
Place of Origin :
Shaanxi, China
Brand Name :
LEEO
Model Number :
LA-10-120
Supply Ability :
200 units/ per Month
Price :
$2000---$5000/unit
Certification :
CE
MOQ :
1-5 units
Delivery Time :
10-20 work days
Product name :
Tail Lift Gates
Description :
Heavy Truck Spare Parts
Application :
Van Truck
Payment Terms :
T/T
MOQ :
5 Sets
OEM :
Avaliable
Warranty :
1 Year
Material :
Steel or Aluminum Alloy
Description

1000 kg loading capacity tail lift gate hydraulic tail lift for truck

Product Description

Platform Dimension (Width* height) 2000 * 1800 MM(also can do customized)
Platform Weight 290-400 KG(depends on material)
Operating Voltage DC12V/24V
Power 2KW
Load Rated 1000 KG
Max Lift Height 1200 MM
Platform Material Steel or Aluminum Alloy

What is a hydraulic tailgate?


A Liftgate, which can also be referred to as a Tail lift, is a mechanical device which is installed permanently at the back or the rear end of a large vehicle like a truck, a lorry or a van. It is used to load and unload freight from the ground and into the back of the truck.

The majority of tail lifts are hydraulic or pneumatic in operation, although they can be mechanical, and are controlled by an operator using an electric relay switch.

Tail lifts make it easier to safely load and unload trucks and are synonymous with cost efficiency, flexibility and a high level of operating comfort for users.

Power Adopt the original imported pumping station from Sweden HALDEX, split integrated structure, fully enclosed and integrated, large-capacity fuel tank, high-performance DC motor, starter, built-in flow control valve (adjustable lifting and turning speed), multiple safety valves, and electrical circuits For integrated circuit modules, the humanized design brings customers a comfortable experience.

Why Choose US

A>Our products the technical starting point at the highest level in China.

B> Our Philosophy is: Active service, Pursuit of perfection

C> To ensure quality our product hydraulic system selects European well-known brands—HALDEX, PAKER.MPI

D> We are proficient in products, understand customers, put people first, and pursue excellence.

Main Products Parameter

Model No Load capacity (KG) Height from Ground to Carriage (MM) Platform Dimension (W*H) MM Operating Voltage (V) Lifting Speed (CM/S) Total weight (KG)
Steel Aluminum Alloy
LA-7-90 700 800-900 1600*1700 12 6-9 320 260
LA-10-120 1000 950-1200 1800*1700 12/24 6-9 390 290
LA-15-120 1500 950-1200 2000*1700 12/24 6-9 450 330
LA-15-135 1500 1050-1350 2200*1800 24 6-9 490 370
LA-15-152 1500 1150-1520 2300*1800 24 6-9 550 430
LA-20-135 2000 1050-1350 2400*1800 24 6-9 520 410
LA-20-152 2000 1150-1520 2400*1800 24 6-9 580 460
LA-25-152 2500 1150-1520 2400*1800 24 6-9 630 490
LA-25-160 2500 1150-1600 2400*1800 24 6-9 750 590

Company Profile

Xi'an Leeo Hydraulic Equipment Co., Ltd., established in August 2011, is located in the beautiful historical city - Xi'an, Shaanxi Province. It is a professional manufacturer of "truck hydraulic tailgate lift" products of high-tech private enterprises, the company gathered a number of domestic and foreign outstanding truck tailgate lift industry specialized persons, concentrate, professional, focus on truck tailgate lifts products and parts of the technology research and development, manufacturing and sales, "integrity, innovation, creating value for customers" business philosophy, To build "LEEO ® " tailgate lift high-end national brand, based on the domestic, look at the world, exhausted and domestic and foreign automobile manufacturing enterprises, logistics and transport enterprises and the community sincere cooperation and provide excellent products and the highest quality services.

1000Kg Loading Hydraulic Tail Lift 1.2m Truck Tail Gate Lift

FAQ

Q:HOW AHOUT THE DELIVERY TIME?

A:THE DELIEVERY TIME IS ABOUT 10-15 DAYS AFTER RECEIPT DEPOSITE.

Q:HOW ABOUT THE PAYMENT?

A:WE USED T/T 50% AS DEPOSIT AND BALANCE BEFORE SHIPMENT.

Q: HOW LONG IS THE WARRANTY TIME?

A:2000 WORKING HOURS OR 12 MONTHS,WHICHEVER COMES FIRST.

Q: WHAT ABOUT THE AFTER-SALE SERVICE?

A: IF THERE ANY QUALOTY ISSUE, PLEASE SEND US THE PHOTOS OR VIDEO,WE WILL OFFER THE SOLUTION WITHIN 24 HOURS.
