DC12V Lorry Tail Gate 700kg Heavy Duty Lift Gate Smart
DC12V Lorry Tail Gate 700kg Heavy Duty Lift Gate Smart
DC12V Lorry Tail Gate 700kg Heavy Duty Lift Gate Smart
DC12V Lorry Tail Gate 700kg Heavy Duty Lift Gate Smart
Specifications
Place of Origin :
Shaanxi, China
Brand Name :
Leeo
Model Number :
LA-7-90
Supply Ability :
200 units/ per Month
MOQ :
1-5 units
Price :
$2000---$5000/unit
Certification :
CE
Delivery Time :
10-20 work days
Type :
Doors
Size :
1600*1700
Description :
Heavy Truck Spare Parts
Application :
Van Truck
Color :
Customer Demands
Payment Terms :
T/T
MOQ :
5 Sets
OEM :
Avaliable
Description

Wholesale Lorry Tail Gate Smart Truck Ford Escqpe Power Lift Tail Gate

Product Description

Main cable: National standard YH-25mm²/8.5m

Hydraulic oil:L-HM series 46# anti-wear hydraulic oil, 10 liters/set

Valve: Import from famous Swedish brand

Load Rated: 700KG

Max Lift Height:900MM

Platform Material: Steel or Aluminum alloy

Platform Dimension (Standard size: Width * Height) 1600 *1700 MM

Platform Weight (KG): Steel 320 Aluminum Alloy 260

Operating Voltage:DC12V/24V

Power:2.5KW

System Pressure:18Mpa

Lift Speed:60-90mm/s (adjustable speed)

What is cantilever tail lift?

Cantilever tail-lifts are stowed vertically and form part or all of the rear closure. The platform has an angled lip at the end allowing it to be rotated downwards. This allows roll cages and pallet trucks to be easily loaded from ground level.

Power Adopt the original imported pumping station from Sweden HALDEX, split integrated structure, fully enclosed and integrated, large-capacity fuel tank, high-performance DC motor, starter, built-in flow control valve (adjustable lifting and turning speed), multiple safety valves, and electrical circuits For integrated circuit modules, the humanized design brings customers a comfortable experience.

Tail lifts make it much easier to safely load and unload trucks and are synonymous with cost efficiency, flexibility and a high level of operating comfort for users.

Why Choose US

A>Our product hydraulic system selects European well-known brands—HALDEX, PAKER.MPI to ensure quality

B> Our Philosophy is: Active service, Pursuit of perfection

C> Our products have a high technical starting point: they are at the highest level in China.

D> We are a professional team and we are proficient in products, understand customers, put people first, and pursue excellence.

Main Products Parameter

Model No Load capacity (KG) Height from Ground to Carriage (MM) Platform Dimension (W*H) MM Operating Voltage (V) Lifting Speed (CM/S) Total weight (KG)
Steel Aluminum Alloy
LA-7-90 700 800-900 1600*1700 12 6-9 320 260
LA-10-120 1000 950-1200 1800*1700 12/24 6-9 390 290
LA-15-120 1500 950-1200 2000*1700 12/24 6-9 450 330
LA-15-135 1500 1050-1350 2200*1800 24 6-9 490 370
LA-15-152 1500 1150-1520 2300*1800 24 6-9 550 430
LA-20-135 2000 1050-1350 2400*1800 24 6-9 520 410
LA-20-152 2000 1150-1520 2400*1800 24 6-9 580 460
LA-25-152 2500 1150-1520 2400*1800 24 6-9 630 490
LA-25-160 2500 1150-1600 2400*1800 24 6-9 750 590

Company Profile

Xi'an Leeo Hydraulic Equipment Co., Ltd., established in August 2011, is located in the beautiful historical city - Xi'an, Shaanxi Province. It is a professional manufacturer of "truck hydraulic tailgate lift" products of high-tech private enterprises, the company gathered a number of domestic and foreign outstanding truck tailgate lift industry specialized persons, concentrate, professional, focus on truck tailgate lifts products and parts of the technology research and development, manufacturing and sales, "integrity, innovation, creating value for customers" business philosophy, To build "LEEO ® " tailgate lift high-end national brand, based on the domestic, look at the world, exhausted and domestic and foreign automobile manufacturing enterprises, logistics and transport enterprises and the community sincere cooperation and provide excellent products and the highest quality services.

DC12V Lorry Tail Gate 700kg Heavy Duty Lift Gate Smart

FAQ

Q:HOW TO DELIVERY THE GOODS.

A: BY SEA OR BY RAILWAY.

Q:HOW AHOUT THE DELIVERY TIME?

A:THE DELIEVERY TIME IS ABOUT 10-15 DAYS AFTER RECEIPT DEPOSITE.

Q:HOW ABOUT THE PAYMENT?

A:WE USED T/T 50% AS DEPOSIT AND BALANCE BEFORE SHIPMENT.

Q: HOW LONG IS THE WARRANTY TIME?

A:2000 WORKING HOURS OR 12 MONTHS,WHICHEVER COMES FIRST.

Q: WHAT ABOUT THE AFTER-SALE SERVICE?

A: IF THERE ANY QUALOTY ISSUE, PLEASE SEND US THE PHOTOS OR VIDEO,WE WILL OFFER THE SOLUTION WITHIN 24 HOURS.
