Low Pressure Electric Gear Oil Transfer Pump 10 Mpa Max Pressure Small Size
Low Pressure Electric Gear Oil Transfer Pump 10 Mpa Max Pressure Small Size
Specifications
Brand Name :
Other
Model Number :
LSG03/05/08
Certification :
ISO9001,Europe-CE,
Place of Origin :
Dongguan China
MOQ :
10 Sets
Payment Terms :
T/T
Supply Ability :
1000
Delivery Time :
5~15 working day
Packaging Details :
Carton box
Structure: :
Gear Pump
Usage: :
Grease Lubrication Pump
Application: :
Lubrication
Power: :
Electric
Fuel :
Grease
Pressure :
Low Pressure
Theory :
Rotary Pump
Oil tank :
Plastic
Throught :
150/200cc
Oil let direction: :
left or rigt
throughout diameter: :
4,6
oil cup volume: :
0.8 or 1.2 L
Max Pressure: :
10.0 Mpa
Price :
Negotiable
Description

Small hydraulic pump central lubrication system electric oil gear pump dispenser pump

Low Pressure Electric Gear Oil Transfer Pump 10 Mpa Max Pressure Small Size

Product Description

* Liquid level switch and pressure switch(optional) are provided. When oil volume
or pressure is insufficient, abnormal signal is output
* The panel indicator light indicates power and lubrication status of the owin/ection
* The system is provided with FEED key, and compulsory lubrication is applied
mold
* Time setting: single maximum lubrication duration s 2min, and intermittent time
* The motor is provided with self-protection to prevent hign temperature and
shall be 5 times of the lubricating time
overload of motor
* Decompression device is provided with resistance-type system, used with
proportional joint distributor
* Overflow valve is provided to prevent damage by oil injector and pipeline
Internal fuse is provided to prevent IC board and motor damaged by short
circuit

Low Pressure Electric Gear Oil Transfer Pump 10 Mpa Max Pressure Small Size
