Stainless Steel Hot Air Hopper Dryer Temperature Keeping For Plastic Material
Stainless Steel Hot Air Hopper Dryer Temperature Keeping For Plastic Material
Stainless Steel Hot Air Hopper Dryer Temperature Keeping For Plastic Material
Stainless Steel Hot Air Hopper Dryer Temperature Keeping For Plastic Material
Specifications
Brand Name :
TOP-Star
Model Number :
THD Series
Certification :
ISO9001,Europe-CE,
Place of Origin :
China
MOQ :
3sets
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
300per month
Delivery Time :
10 working days
Packaging Details :
wooden case
Description

THD Series Hopper Dryers

Hopper Dryers are mainly applied to plastic material drying. Hot air is used to dry all wet materials which gain an even hot air flow to improve drying efficiency for assuring quality of products. Hopper capacities rang from 12kgs ~1000kgs can be offered for selection.
Exhaust air filter (option) can filter the dust-contain air effectively from discharging to the surrounding area. Hot air recyclers (option) to make hot air form a semi- closed circulated loop to speed up hot air circulation for shorten heating time to achieve energy saving up to 30%.

Stainless Steel Hot Air Hopper Dryer Temperature Keeping For Plastic Material

Features

◆All material contact surfaces are made of stainless steel to avoid material contamination.
◆Precise aluminum casting hopper barrel features smooth surface & good performance on temperature keeping .
◆Sound-proof blower with anti-dust design eliminates dust for ensuring material free from contamination.
◆Hopper barrel is fitted with see-through windows to observe inside material level.
◆Hot air inlet elbow design can prevent dust piling up at the bottom of the heaters to avoid burning
◆To adopt hot air diffuser for acquiring an even hot air flow to improve drying efficiency.
◆Hopper barrel separated from its base for easy cleaning.
◆Safety device with overheat and overload protection.
◆24 hours auto start/stop timers are available as option.

Stainless Steel Hot Air Hopper Dryer Temperature Keeping For Plastic Material

Model Unit THD-12U THD-25U THD-50U THD-75U THD-100U THD-150U THD-200U THD-300U
hopper capacity KG 12 25 50 75 100 150 200 300
blower power W 75 135 155 155 215 215 320 320
Heater power KW 1.8 3.0 4.0 4.0 6.0 9.0 12.0 15.0
Dryer Temp ℃ Max 150℃
Outlet size Inch 2.5 2.5 2.5 2.5 2.5 2.5 2.5 3.5
Hopper body dia mm 295 347 423 495 562 600 687 759
Flange ID dia mm 42 61 74 74 81 81 110 110
Flange PCD dia M Open according to the actual size
Flange OD dia M 0.13 0.17 0.2 0.2 0.23 0.23 0.25 0.295
Blower PCD Dia M 0.136 0.163 0.208 0.254
Blower OD dia M 0.148 0.18 0.22 0.27
Power supply V 380V AC3P/PE 50HZ
Control voltage V 220V AC1P/PE 50HZ
Total Power KW 2 3.5 4.5 4.5 6.4 9.4 12.5 15.5
wires specification mm2 5X1.5 5X2.5 4X4+1X2.5 4X6+1X4
wires Length M 5
Outside Dimensions L (m) 0.66 0.75 0.83 0.9 1 1.04 1.23 1.28
W (m) 0.42 0.48 0.52 0.55 0.661 0.635 0.685 0.765
H (m) 0.8 0.994 1.165 1.263 1.335 1.533 1.695 1.847
weight kg 21 34 38 46 59 85 114 140
Optional Accessories 1. Magnetic Seat. 2.Hopper Magnet 3.Hot air recycler 4. Exhaust air filter 5. Type floor stands 6. A type floor stands 7. Material suchion box
