CATV Rack Mount 1x64 PLC Splitter Single Mode G657A With SC APC Pigtail
CATV Rack Mount 1x64 PLC Splitter Single Mode G657A With SC APC Pigtail
Specifications
Brand Name :
DF/Takfly/Neutral
Model Number :
TK-PLC-1x64-SA-RM
Certification :
CE/ROHS/REACH/ISO9001/ISO14001
Place of Origin :
Shenzhen, China
MOQ :
30
Price :
US$0.01~US$79.99/PC
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000PCS/Week
Delivery Time :
5-7 Working days
Packaging Details :
Export Standard packing
Product Name :
CATV 1x64 Rack Mount PLC Splitter
Fiber type :
G.657A
Wavelength :
1260 ~ 1650nm
Cable diameter :
2.0mm
Insertion Loss :
≤20.3dB without connector
Return Loss :
≥55dB
Packing Size :
1U 19Inch
Max. Uniformity :
2.0dB
Operating temperature :
-40 ~ +85
Application :
FTTX, CATV
Description

CATV 1x64 Rack Mount PLC Splitter , Single Mode G657A , With SCAPC Pigtail , 1U 19 Inch For FTTX

Fiber Optic PLC Splitter Description

The full name of PLC Splitter is Planar Lightwave Circuit Splitter. It adopts silica optical waveguide technology and is used for optical power allocation from the central office to customer premises in FTTx and FTTH networks.

PLC Splitter offers a cost-effective and space-saving networking solution in an optical transmission system.

PLC splitter is an optical power distribution device based on the integrated waveguide of quartz plate. With the features of small size, wide range of operating wavelength, stable reliability and good uniformity, It’s widely used in PON,ODN,FTTX point to connect between termination device and central office to achieve the signal splitter.

CATV Rack Mount 1x64 PLC Splitter Single Mode G657A With SC APC Pigtail

CATV Rack Mount 1x64 PLC Splitter Single Mode G657A With SC APC Pigtail

Fiber Optic PLC Splitter Applications

PLC splitter was widely used in all kinds of optical network solutions , such as Security Monitoring, Optical Communication, Network Construction, CATV and Pon network.

● Telecommunication sector

● PON Syster

● FTTH

● CATV

● Video Transmission

Fiber Optic PLC SplitterSpecification

Item Parameter
Operating Wavelength(nm) 1260 ~ 1650
Type(1*N) 1*2 1*4 1*8 1*16 1*32 1*64
Max.Insertion Loss (dB) 3.9 7.2 10.3 13.5 16.8 20.3
Max.Uniformity(dB) 0.8 0.8 0.8 1.0 1.5 2.0
Min.Return Loss(dB) 55
Max.PDL(dB) 0.2 0.3 0.3 0.3 0.3 0.5
Type(2*N) 2*2 2*4 2*8 2*16 2*32 2*64
Max.Insertion Loss(dB) 4.2 7.5 10.6 13.9 17.2 20.8
Max.Uniformity(dB) 0.8 1.0 1.2 1.5 1.8 2.0
Min.Return Loss(dB) 55
Max.PDL(dB) 0.2 0.3 0.3 0.3 0.3 0.5
Fiber Type ITU-T G657A1 , G657A2 and G.652D
Max.Temperature Stability(dB) 0.5( Typical 0.3 )
Operating Temperature(℃) -40 ~ +85
Storage Temperature(℃) -40 ~ +85

All measurement are made at room temperature, and connectors not included

Fiber Optic PLC Splitter Packing Dimension

Package type Unit(mm) 1*2 1*4 1*8 1*16 1*32 1*64
Basic Packagin Metel box L×W×H 40*4*4 40*4*4 40*4*4 50*7*4 60*7*4 60*12*4
Mini Module Packagin Metel box 60*7*4 60*7*4 60*7*4 60*12*4 80*20*6 100*40*6
Module Packagin Plastic box 100*80*10 100*80*10 100*80*10 120*80*18 120*80*18 140*115*18

Package type Unit(mm) 2*2 2*4 2*8 2*16 2*32 2*64
Basic Packagin Metel box L×W×H 60*7*4 60*7*4 60*7*4 60*7*4 80*20*6 80*20*6
Mini Module Packagin Metel box 60*7*4 60*7*4 60*7*4 80*12*4 80*20*6 100*40*6
Module Packagin Plastic box 100*80*10 100*80*10 100*80*10 120*80*18 120*80*18 140*115*18

With 21 years manufacturing experince in Fiber Optic Products, Takfly Group have a wide of PLC Splitters for your option, such as 250μm bare fiber PLC Splitter, 900μm mini steel tube PLC Splitter, ABS Box PLC Splitter, LGX Cassette type PLC Splitter, Rack Mount PLC Splitter, ect.

Takfly PLC Splitters have below advantages:

1. CE, ROHS, ISO9001, ISO14001 certified.

2. High performance, low insertion loss.

3. Branch Numbers from 1x2, 1x4, 1x8, 1x16, ....1x128, and 2x2, 2x4, 2x8, 2x16, 2x32, ......2x128, also with Non-standard 1x3 1x6 1x12 for options.

4. OEM Brand is availble.

If you’re dealing with FTTX, FTTH projects, welcome to inquire us for more details.
