1.25G SFP BIDI Transceiver Tx1310/Rx1550nm 40KM SMF DDM LC SFP OPTICAL TRANSCEIVER MODULE
1.25G SFP BIDI Transceiver Tx1310/Rx1550nm 40KM SMF DDM LC SFP OPTICAL TRANSCEIVER MODULE
1.25G SFP BIDI Transceiver Tx1310/Rx1550nm 40KM SMF DDM LC SFP OPTICAL TRANSCEIVER MODULE
1.25G SFP BIDI Transceiver Tx1310/Rx1550nm 40KM SMF DDM LC SFP OPTICAL TRANSCEIVER MODULE
1.25G SFP BIDI Transceiver Tx1310/Rx1550nm 40KM SMF DDM LC SFP OPTICAL TRANSCEIVER MODULE
1.25G SFP BIDI Transceiver Tx1310/Rx1550nm 40KM SMF DDM LC SFP OPTICAL TRANSCEIVER MODULE
1.25G SFP BIDI Transceiver Tx1310/Rx1550nm 40KM SMF DDM LC SFP OPTICAL TRANSCEIVER MODULE
1.25G SFP BIDI Transceiver Tx1310/Rx1550nm 40KM SMF DDM LC SFP OPTICAL TRANSCEIVER MODULE
Specifications
Brand Name :
Takfly/OEM
Model Number :
SFP-1G-BX-U40
Certification :
ISO9001, ISO14001, CE, REACH, ROHS, FCC
Place of Origin :
Shenzhen China
MOQ :
1 piece
Price :
4.71 USD/PIECE
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000 pieces per week
Delivery Time :
2~3 days
Packaging Details :
10 pieces/box
Form Factor :
SFP
Max. Data Rate :
1000Mbps
Wavelength :
1310nm-TX/1550nm-RX
Max. Cable Distance :
40km
Media :
SMF
Connector :
Simplex LC
TX Power :
-5~0dBm
Receiver Sensitivity :
-24dBm
DDM/DOM :
Supported
Commercial Temperature Range :
0 to 70°C
Description

1.25G SFP BIDI Tx1310/Rx1550nm 40KM SMF DDM LC CISCO JUNIPER HUAWEI COMPATIBLE SFP OPTICAL TRANSCEIVER MODULE

The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 40KM transmission distance with SMF.

The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Applications
  • Gigabit Ethernet
  • Fiber Channel
  • Switch to Switch interface
  • Switched backplane applications
  • Router/Server interface
  • Other optical transmission systems
Features​
  • Dual data-rate of 1.25Gbps/1.063Gbps operation
  • 1310nm DFB laser and PIN photodetector for 40KM transmission
  • Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
  • Digital Diagnostic Monitoring: Internal Calibration or External Calibration
  • Compatible with SONET OC-24-LR-1
  • Compatible with RoHS
  • +3.3V single power supply
  • Operating case temperature range: 0 °C to +70 °C (Commercial), -40 °C to +85 °C (Industrial)
1.25G SFP BIDI Transceiver Tx1310/Rx1550nm 40KM SMF DDM LC SFP OPTICAL TRANSCEIVER MODULE1.25G SFP BIDI Transceiver Tx1310/Rx1550nm 40KM SMF DDM LC SFP OPTICAL TRANSCEIVER MODULE
