380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine
380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine
380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine
380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine
380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine
380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine
380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine
380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine
380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine
380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine
380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine
380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine
Specifications
Brand Name :
Trancar Industries
Model Number :
TCM-PM
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD 9000-50000 Dollar per set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
25 sets per Month
Delivery Time :
35 work days
Packaging Details :
Custom design plywood box
Product Name :
Steel Flat plate sheet automatic polishing machine
Dimension :
6500x3000x1200 mm
Weight :
3800kg
Voltage :
380V 400V 415V etc
Usage :
Steel sheet surface polishing brushing
Condition :
100% new
Control system :
Semi-automatic button control with PLC program
Polishing efficiency :
8-15 m2 per hour
Warranty :
18 Month
Provide :
ODM & OEM
Description

Steel Flat plate sheet surface automatic polishing machine

Trancar Industries TCM-PM polishing machine is a type of stainless steel surface finishing machine,it could do dust removing,welded joint’s surface grinding and mirror surface buffing for steel metal flat plate sheets.

It’s mainly used to polish & grind various materials of large plate sheets, such as the polishing of composite sheets and carbon steel plate before the composite grinding & surface finishing after sheet compounding.It’s especially suitable for the polishing,grinding and drawing of stainless steel plate.Due to the movement of the grinding head and the grinding method of the flat plate sheet,the length of the sheet is less than 10 meters,and the machine guide rail can be revised accordingly.Flat sheet automatic polishing machine are widely used in the field of Food processing,catering,brewing and chemical.

TCM-PM Steel Flat plate sheet automatic polishing machine parameter:

Normal configuration(customer design acceptable)

Steel metal sheet size

Max.Available Width

800 / 1500 / 2000 mm

Thickness

≧1.5 mm

Length

≦10,000 mm

Machine Dimension

(L×W×H) 6500×3000×1200 mm

Polishing Precision

Surface roughness(Ra)

<=0.8μm

Production Efficiency

Polishing working speed

6~12 m2/h

Input total Power

8Kw/12Kw /20kw

Power Supply

380V 415V / 50Hz 60HZ / 3p or Customization

Machine Weight

/

3800kg

Color

Grey/Green/Blue/Red/Yellow Custom design

Suitable Polishing Materials

Abrasive sanding belts,grinding wheels.

(flap/cloth/ emery/Nylon wheel etc)

380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine

380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine

380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine

380V 400V 415V Steel Flat Plate Surface Automatic Sheet Polishing Machine

Contact Trancar Industries for more steel sheet surface automatic polishing brushing solutions:
