300kg Vessel Rotary Welding Positioners With Servo Motor CE Certified
300kg Vessel Rotary Welding Positioners With Servo Motor CE Certified
300kg Vessel Rotary Welding Positioners With Servo Motor CE Certified
300kg Vessel Rotary Welding Positioners With Servo Motor CE Certified
300kg Vessel Rotary Welding Positioners With Servo Motor CE Certified
300kg Vessel Rotary Welding Positioners With Servo Motor CE Certified
300kg Vessel Rotary Welding Positioners With Servo Motor CE Certified
300kg Vessel Rotary Welding Positioners With Servo Motor CE Certified
300kg Vessel Rotary Welding Positioners With Servo Motor CE Certified
300kg Vessel Rotary Welding Positioners With Servo Motor CE Certified
Specifications
Brand Name :
weldsuccess
Model Number :
HB12
Certification :
CE
Place of Origin :
CHINA
MOQ :
1set
Price :
Negotiable
Supply Ability :
20sets/month
Delivery Time :
20days
Packaging Details :
Seaworthy Packages
Description

Vessel Welding Positioner Turntable with Servo Motor , CE Certified

Quick Detail:

  • HB self-adjustable welding positioner which consists of working table and pedestal.
  • Working table can do two acts as revolving infinitely and tilted within degree 0°～120°, which make the tank at ideal position.
  • Can add a chuck in the welding table to fix (clamp) the work-piece well.
  • With T-slots on the table surface for clamping work-piece

Description:

Welding positioner is consisting of worktable revolving mechanism, overturning device and electric control system. T

he work-piece can be reach to the most suitable position through worktable revolving and overturning device.

The worktable revolving controlled by step-less frequency conversion to achieve a best welding speed.

Standard type welding positioner can't meet all work-pieces’ processing, please provide your work-piece’s weight,

shape and other specification in detail so that we can provide the best solution way for your reference.

Specifications:

Model

Rated weight bearing(kg)

rotation speed (rpm)

Speed of table tiling (rpm)

Turning angle(°)

Size of working table(mm)

Turning

Over turning

May of

setting

Max distance of gravity center(mm)

Max distance of distance(mm)

Max turning diameter(mm)

HB-01

100

0.1-1

By manual

0-120

Φ400

0.18

/

Frequency conversion stepless speed

100

150

Φ600

HB-03

300

0.2-2

By manual

0-90

Φ600

0.18

/

100

100

Φ800

HB-06

600

0.09-0.9

1.1

0-90

Φ1000

0.75

0.75

100

100

Φ1500

HB-12

1200

0.05-0.5

0.67

0-90

Φ1200

1.1

1.1

150

100

Φ2050

HB-30

3000

0.05-0.5

0.23

0-120

Φ1400

1.5

1.5

200

150

Φ2100

HB-50

5000

0.05-0.5

0.14

0-120

Φ1500

2.2

3

300

200

Φ2500

HB-100

10000

0.05-0.2

0.14

0-120

Φ2000

3

5.5

400

250

Φ3240

Applications:

It used in many industries such as pipe, tank, pressure vessel, boiler, freezing equipment, power station construction,

metallurgical, engineering machinery, marine building, and petro-chemical industries etc.
