Conventional 2000kg Welding Rotator Turntable Equipment For Piping Industry
Conventional 2000kg Welding Rotator Turntable Equipment For Piping Industry
Conventional 2000kg Welding Rotator Turntable Equipment For Piping Industry
Conventional 2000kg Welding Rotator Turntable Equipment For Piping Industry
Conventional 2000kg Welding Rotator Turntable Equipment For Piping Industry
Conventional 2000kg Welding Rotator Turntable Equipment For Piping Industry
Conventional 2000kg Welding Rotator Turntable Equipment For Piping Industry
Conventional 2000kg Welding Rotator Turntable Equipment For Piping Industry
Specifications
Brand Name :
weldsuccess
Model Number :
XHGK40
Certification :
CE
Place of Origin :
CHINA
MOQ :
1set
Price :
Negotiable
Supply Ability :
20sets/month
Delivery Time :
20days
Packaging Details :
Seaworthy Packages
Name :
Conventional welding rotator
Roller material :
Rubber or PU or Metal
Loading capacity :
2000kg
Range of suitable work piece :
200mm-1200mm
Power of motor :
2×0.18kw
Usage :
Heavy Duty Rotator
Description

2000kg Heavy Duty Rotator Pipe Welding Turntable For Piping Industry

Quick Detail:

The distance between two rollers can be adjustable by bolt fasten, to accommodate work-piece of variable diameters.

The equipment features in good adaptation, smooth revolve, VFD adjustable revolve speed and displaying in linear

speed, which is suitable for welding, polishing, assembly for pipe/tank/vessel longitudinal and transverse seam welding.

Our company also can customize welding rotator in all varieties according to client's requirements.

pipe rotator for welding Applications:

It used in many industries such as pressure vessel, boiler, freezing equipment, power station construction,

metallurgical, engineering machinery, marine building, and petro-chemical industries etc.

Specifications:

Type

Max loading (kg)

Range of suitable work piece(mm)

Dia. and width of the wheel(mm)

roller linear velocity(m/h)

Power of motor(kw)

Adjustable mode for space

Way of setting

Rubber rollers

Metal rollers

XHGK-2

2000

Φ200-1200

Φ200×100

2×Φ190×16

6-60

2×0.18

Manual screw adjustment or bolt shift

AC converter stepless speed adjust

XHGK-5

5000

Φ250-2300

Φ250×100

2×Φ240×20

6-60

2×0.37

XHGK-10

10000

Φ300-2800

Φ300×120

2×Φ290×25

6-60

2×0.55

XHGK-20

20000

Φ500-3500

Φ350×120

2×Φ340×35

6-60

2×1.1

XHGK-40

40000

Φ600-4200

Φ400×120

2×Φ390×45

6-60

2×1.5

XHGK-60

60000

Φ750-4800

Φ450×120

2×Φ440×60

6-60

2×2.2

Bolt shift

XHGK-80

80000

Φ850-5000

Φ500×120

2×Φ490×70

6-60

2×3

XHGK-100

100000

Φ1000-5500

Φ500×120

2×Φ490×100

6-60

2×4

XHGK-150

150000

Φ1100-6000

/

Φ620×220

6-60

2×4

XHGK-250

250000

Φ1100-7500

/

Φ660×260

6-60

2×5.5

XHGK-400

400000

Φ1100-7500

/

Φ750×320

6-60

2×7.5

XHGK-500

500000

Φ1100-7500

/

Φ750×400

6-60

2×11

Note: For 2-100T roller is steel and rubber combination roller.For 100-500T roller is made of whole steel roller or imported rubber.
