Two Axle 8 Tires 30 Ton 40 Feet Chassis Container Trailer Skeletal Semi Trailer
Two Axle 8 Tires 30 Ton 40 Feet Chassis Container Trailer Skeletal Semi Trailer
Two Axle 8 Tires 30 Ton 40 Feet Chassis Container Trailer Skeletal Semi Trailer
Two Axle 8 Tires 30 Ton 40 Feet Chassis Container Trailer Skeletal Semi Trailer
Specifications
Brand Name :
Fudeng
Model Number :
SDFD1705 chassis trailer
Certification :
CE, ISO, CCC, SGS, ADR
Place of Origin :
Shandong, China
MOQ :
1 set
Price :
negotiation
Payment Terms :
L/C, T/T or negotiate
Supply Ability :
600 sets per month
Delivery Time :
25-40 days after 30% deposit
Packaging Details :
Paint and wax spraying
Material :
Carbon Steel
Usage :
Transport 20ft And 40ft Container
Color :
White, Yellow, Red, Green, Blue Customized
Pattern :
Fudeng Logo Or As Customer's Request
Suspension :
Mechanical Or Air Suspension
Capacity :
30-50 Ton Available
Axle :
Fuwa or BPW brand
Conditions :
New
Tires :
12R22.5 Vacuum Tire / 11.00R20
Description

40 feet Container skeletal semi Trailer two axle 8 tires 30 ton load capacity

Container chassis semi-trailer are designed for 20ft 40ft 45 ft container and sea freight transport tasks and combine both safe and rapid container handling. The welded container trailer possesses a long service life even under the tough conditions which a semi-trailer container chassis has to face on a daily basis.

The Advantages

· 12 sets of twist lock chassis trailer for transporting 2 x 20' or 1 x 40' different containers

· Pneumatic hook locks for maximum safety

· Dual-tyre optional for greater load capacity

40ft container skeleton trailer chassis for sale
Type semi-trailer chassis
Function 2x 20ft and 1x40ft container or other stuff
Weight
Loading capacity kg 40000 KG
Tare weight kg 6000KG
Specification
Dimensions(L*W*H) mm 12500*2500*1600
Main Beam

Heavy duty and extra durability designed I beam;

opting for high tensile steel Q345,

welded by automatic submerged-Aac processes.

Top flange 14mm,width140mm;Middle

Flange 8mm;bottom flange16mm,width 140mm
Axle number 3
Axle weight load 13Ton
Axle brand FUWA
Tire type 12R22.5, 11R20, 315/80R22.5
Container twist locker 12 no.of ISO twist lock for 1x20ft,2x20ft,1x40ft container
King pin 3.5"(90#) removeable
Support legs 28Ton standard
Leaf spring Leaf spring 6 sets
Suspension Mechanical suspension
Braking system WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks
Tools box 2
Electrical
Voltage 24V
Receptacle 7 ways (7 wire harness)
Light
Side marker lamp LED type
Shipping terms Naked
Delivery time 15 workdays after confirming order and receiving your deposit
Miscellaneous
marking According to the requirement of the buyer
painting optional


Two Axle 8 Tires 30 Ton 40 Feet Chassis Container Trailer Skeletal Semi Trailer

Two Axle 8 Tires 30 Ton 40 Feet Chassis Container Trailer Skeletal Semi Trailer

All types can be customized.
