Strong 25 Ton - 35 Ton Low Bed Semi Trailer , Two Axles 8 Wheel Trailer
Strong 25 Ton - 35 Ton Low Bed Semi Trailer , Two Axles 8 Wheel Trailer
Strong 25 Ton - 35 Ton Low Bed Semi Trailer , Two Axles 8 Wheel Trailer
Strong 25 Ton - 35 Ton Low Bed Semi Trailer , Two Axles 8 Wheel Trailer
Strong 25 Ton - 35 Ton Low Bed Semi Trailer , Two Axles 8 Wheel Trailer
Strong 25 Ton - 35 Ton Low Bed Semi Trailer , Two Axles 8 Wheel Trailer
Specifications
Brand Name :
Fudeng
Model Number :
SDFD1702 low bed trailer
Certification :
CE, ISO, CCC, SGS, ADR
Place of Origin :
Shandong, China
MOQ :
1 set
Price :
negotiation
Payment Terms :
L/C, T/T
Supply Ability :
600 sets per month
Delivery Time :
25-40 days after 30% deposit
Packaging Details :
Paint and wax spraying
Material :
Carbon Steel
Usage :
Transport heavy machine
Color :
White, yellow, red, green, blue customized
Pattern :
Fudeng logo or as customer's request
Brake System :
2 line air braking system
Capacity :
30-100 ton available
Axle :
2 or 3 or 4
Landing gear :
Standard 28 Ton
Description

Strong 25 Ton - 35 Ton Low Bed Semi Trailer , Two Axles 8 Wheel Trailer

Fudeng Trailer Company provides a comprehensive ranges of lowbed trailers, to meet all heavy haulage requirements.

All lowbeds are designed and built to meet the harsh conditions synonymous with lowbed transportation. The frames are constructed from Q345B steels (high strength and high tensile), fitted with the highest quality running gear and fabricated and finished off to the standards that the organization is renowned for.

Low low bed semi trailer is a multi functional transport vehicle which offers the optimal economic and technical solution to different transport tasks such as construction machines, farming machines, lifting vehicles, industrial parts and much more.

Strong 25 Ton - 35 Ton Low Bed Semi Trailer , Two Axles 8 Wheel Trailer


Low Bed Trailer
Specification Dimensions
(mm)		 13000x3000-3500x1650 (Standard Or Customized)
Axle Number Three(customized)
Payload 13T/16T
Brand BPW /FUWA/Chinese Brand
Suspension Mechanical Suspension/ Pneumatic Suspension
Rim 6.5-20/7.5-20/8.00-20/8.5-20
Ladder Spring/ Mechanical / Hydraulic ladder
Tires Tires 8.25R22.5/10.00R20/11.00R20/12.00R20
Brand Triangle or Double Coin Brand
King Pin Size 2.0’’ or 3.5’’ traction pin
Brand JOST Brand2.0 or 3.5 inch(bolted or welded type ) or China famous brand
Landing Gear JOST brand D200T or Chinese brand 28Tons28Tons
Frame Main beam

The height of the beam is 450/500mm,upper plate is 14mm down .
Bottom platform 3-6mm thick checkered plate
Additional ABS Optional
Light LED light

Our low bed semi trailer advantages

  1. The main beam is designed as special double vertical plate which is more solid than single vertical plate.
  2. The gooseneck is inside and outside reinforced to achieve heavy duty tranportation.
  3. The ladder and trailer body are connected by mechanical spring make it easy operate and high-intensive.
  4. The side beams are I shaped steel beam structures. Checkered floor aims increase friction and prevent cargo from skidding.

Strong 25 Ton - 35 Ton Low Bed Semi Trailer , Two Axles 8 Wheel Trailer

Strong 25 Ton - 35 Ton Low Bed Semi Trailer , Two Axles 8 Wheel Trailer


Welcome to contact us to get more information.
