3 Axles Bulk Cement Tanker 30-75 CBM Mechanical / Air / Bogie Suspension
3 Axles Bulk Cement Tanker 30-75 CBM Mechanical / Air / Bogie Suspension
3 Axles Bulk Cement Tanker 30-75 CBM Mechanical / Air / Bogie Suspension
3 Axles Bulk Cement Tanker 30-75 CBM Mechanical / Air / Bogie Suspension
3 Axles Bulk Cement Tanker 30-75 CBM Mechanical / Air / Bogie Suspension
3 Axles Bulk Cement Tanker 30-75 CBM Mechanical / Air / Bogie Suspension
3 Axles Bulk Cement Tanker 30-75 CBM Mechanical / Air / Bogie Suspension
3 Axles Bulk Cement Tanker 30-75 CBM Mechanical / Air / Bogie Suspension
Specifications
Brand Name :
FUDENG Brand
Model Number :
Bulk cement tanker trailer
Certification :
CCC, CE, SGS, BV,ADR,DOT
Place of Origin :
Shandong China(Mainland)
MOQ :
One Unit Bulk cement tanker tailer
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500Units per Month
Delivery Time :
20-30days after Deposit
Packaging Details :
Shipping by the Bulk cargo transportation
Price :
negotiation
Product Name :
Bulk cement tanker trailer
Loading capacity :
30-75CBM
Color :
Optional
Tank Thickness :
5mm Tank Thickness Optional
Size :
10500*2500*4000 Or Customized
Landing Gear :
JOST Brand 28Tons
Suspension :
Mechanical / Air / Bogie Suspension
Transportation :
Cement Flour Powder Material Transportation
Description

50ton cement bulker for Malaysia bulk cement tanker price 3 axles bulk powder tanker

Bulk cement tanker trailers Main Features:

1) Frame and kingpins: the frame is steel space frame low-welded structure,

2) Suspension leaf spring suspension system for the triaxial suspension, is used to support the load, and absorbs road vibration and so on.
3) The brake device and its operation: Semi-double pipe pneumatic braking system and equipped with anti-lock braking system (ABS)
4) Electrical system: tractor-trailer has adapted to international common electrical system.
5) External power and air compressor:There is sufficient air pressure 4100 diesel engine and an external dimension 10.00 Wuhu Automotive Compressor group, to ensure that the vehicle when unloading.

Bulk Cement Tank Semi Trailer Application:

1. For dry powder transporting, such as bulk cement, flour, and so on.

2. Volume is optional.

3. High-tensile steel with strong load capacity.

4. Air compressor and diesel engine are equipped.

5. Can be designed according customer's requirement

Specification:

Product Name 3 Axles Bulk cement tanker trailers
Model GJC9400GYY
Brand Name SPECIAL TRAILER
Total Size (L×W×H)(mm) 11500x2500x3700mm
Internal size(mm) 11200x2495x2050mm
Volume 50 tons
Curb weight(kg) 9500
Tank body 5mm carbon steel
End plate 6mm carbon steel
Compartment 1 Pcs
Manhole cover 2 Pcs 500mm manhole cover
Discharge valves 1 Pcs
Air compressor 37 KW,0.2Mpa. 1000r/Min(12m3/minute) Bohai brand
Engine Diesel engine Weichai brand model:4102
Handrail 1 pieces on the top of the tanker body
Ladder 1 piece, in the back of the tanker body
Leaf Spring 10/10/10
Axle 3 axles, 13ton/axle
Axle brand FUWA brand or BPW brand
Wheel Base(mm) 6950+1310+1310
Suspension Mechanical suspension or air suspension
Support leg Factory standard Brand 28T,two speed landing gear
King pin JOST Brand 50# or 90#
Tire 1100R20 12 pieces
Rim 9.0-20 12 pieces
Brake chamber 6 double chamber
Voltage 24V
Receptacle 7 ways (7 wire harness)
Light LED light
Tool box 1 Pcs
Spare tire carrier 1 Pcs
Painting Optional(QICAI brand)
Delivery time 20 working days after receive the deposit

40CBM Bulk cement tanker trailers.

3 Axles Bulk Cement Tanker 30-75 CBM Mechanical / Air / Bogie Suspension

1. 30m³-75m³ capacity available
2.Unloading speed: 1.3ton / mins

3.Residual ratio :<15kg

35Tons Bulk cement tanker trailers.

3 Axles Bulk Cement Tanker 30-75 CBM Mechanical / Air / Bogie Suspension

Welcome to visit our factory!
