Double Axles Cement Tank Trailer With Mechanical Suspension, 30CBM Cement Trailer
Double Axles Cement Tank Trailer With Mechanical Suspension, 30CBM Cement Trailer
Double Axles Cement Tank Trailer With Mechanical Suspension, 30CBM Cement Trailer
Double Axles Cement Tank Trailer With Mechanical Suspension, 30CBM Cement Trailer
Specifications
Brand Name :
Fudeng
Model Number :
FDZH040608
Certification :
CCC, CE, SGS, BV
Place of Origin :
Shandong, China
MOQ :
1 set
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
200 sets per month
Delivery Time :
25 - 35 days
Packaging Details :
bulk cargo
Tank Thickness :
Optional
Diesel Engine :
Weichai
Suspension :
Mechanical
Logo :
As Customers′ Request
Tire :
12R22.5 / 11.00R20
King pin :
2" or 3.5" JOST
Condition :
New
Max Payload :
30T
Price :
negotiation
Description

2 axle cement tank trailer for transporting 30tons cement , 25CBM cement trailer

1 .The bulk cement semi trailer, also known as powder material truck, is suitable for the bulk transport of cement, coal ash, lime powder, mineral powder, caustic soda, and other dry powder materials with the particle diameter no more than 0.1mm. Capable of saving a lot of packaging materials and handling labor, it is mainly used in cement factories, cement warehouses, and large construction sites.

2 . The tank of the bulk cement semi trailer mainly consists of barrel, fluidized bed, discharge pipe assembly, intake pipe, and other accessories. There are two or three feed ports at the top of the tank. The front and rear air chambers are set with one intake pipe respectively. Simultaneous open and separate control can be realized respectively through the ball valve.

3 . Power taken out from the vehicle gearbox drives the air compressor through the transmission device. The compressed air goes into the air chamber through the control pipeline and makes the powder material inside the tank fluidize. When the pressure reaches 0.196Mpa, the discharge butterfly valve is opened to realize discharge.


Specification

Bulk cement tanker trailer
Dimension 9.5 m×2.5m×4.0m
Shape V shape
Payload 30 m³
Compartment Single
Tanker Body thickness 4 mm
End Plate thickness 5 mm
Manhole Cover 2 pieces
Air Compressor Wuhu Fuda12 cbm double-cylinder
Diesel Engine Weichai 4102
Chassis
Axle 3 axles 13T,16T brake block, FD brand
Main Beams Q345B carbon steel material
Landing Gear 28T
King Pin 2 inch or 3.5 inch
Suspension Mechanical suspension
Leaf Spring 90mm(W)*16mm(T)*10 Layer
Braking System 3 axle Synchronous,6 big air chamber
Tire 11.00R20,12 pieces
Spare Tire Rack Optional
Accessories One standard tool box
Voltage 24V
Packing and shipping
Shipping Terms By Bulk Cargo/RORO


Details

1 . Strength design for internal support structure can make the tank body stronger and more durable.

2 . The bulk cement tanker semi trailer with the Wechai diesel engine and air compressor ,can have a longer service life .

Double Axles Cement Tank Trailer With Mechanical Suspension, 30CBM Cement Trailer

Double Axles Cement Tank Trailer With Mechanical Suspension, 30CBM Cement Trailer

FAQ


Q1. Are you a manufacturer?
Yes, we have been in special vehicle manufacturing and marketing for over 20 years.


Q2. What information should I let you know if I want to get a quotation?
Please let us know your purpose, road condition, cargo type, tons of your cargo, dimensions of trailer, quantity etc. We can discuss the practicable plan and produce it as your request.


Q3. Terms of payment:
30% contract value sent as the deposit by T/T, 70% balance pay off before delivery time after production finished.


Q4. M O Q (minimum order quantity):
One unit can be accepted. We suggest two trailers one time to save the freight charge.
