Top - Class Steel Frames 3 Axles Side Wall Semi Trailer With Advanced LED Light
Top - Class Steel Frames 3 Axles Side Wall Semi Trailer With Advanced LED Light
Top - Class Steel Frames 3 Axles Side Wall Semi Trailer With Advanced LED Light
Top - Class Steel Frames 3 Axles Side Wall Semi Trailer With Advanced LED Light
Specifications
Brand Name :
FUDENG Brand Side wall semi trailers
Model Number :
Side wall semi trailers
Certification :
CE/BV/CCC/SGS/DOT
Place of Origin :
Shandong,China(Mainland)
MOQ :
One Unit Side wall semi trailers
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500Sets per Month
Delivery Time :
20-25days after deposit
Packaging Details :
nude package Waxing shipping by the 40ft containers Bulk cargo Ro-Ro and so on
Axles :
FUWA/BPW/Chinese brand
Load capacity :
30Tons-60Tons
Suspension :
Mechanical suspension and Air Suspension
Transportation :
20&40ft containers and bulk cargo
Side wall :
1.5mm steel plate 1500mm height
Material :
Steel
Frame Floor :
3mm pattern
Landing Gear :
JOST (D200T) 28T
Price :
negotiation
Description

Cargo fence semi trailer,cargo box trailer with FUWA 13 Ton Axle

Features of Side wall semi trailers:

1. Steel structure: Steel frames are built with top-class hot rolled or rolled steel plate, automatic welded longitudinal beam and adopting advanced sanding and painting process as preliminary treatment.

2. Different types of suspension are designed for various operating condition: Bogie suspension; Air suspension; Mechanical suspension.

3. Lamp assembly uses advanced LED light, top quality PC and cast wire harness in dual circuit design.

4. Automatic tire inflation and pressure sensor system is optionally available for enhanced safety and better fuel economy.

5. State-of-the-art detection devices: Components, hardness, and phase of metal are analyzed to ensure the standards of processed material; Weld seam defects, paint thickness and adhesuveness are checked and amended to guarantee the quality of finished products.

What we can provided:

1>The sides of semi-metal, the front shield and a metal reinforced.

2>The floor is covered with corrugated sheet metal.

3>Heavy duty type suspension

4>Good brake effects. Axles are equipped with WABCO emergency brake valve also dual-brake chamb- ers also widen brake pads

Specification:

PRODUCT PARAMENTERS
Remark This Specification just for your reference, we can produce fence semi trailer as your demands.
Dimensions 12500mm*2600mm*1560mm
Side wall 600mm, 800mm, 10000mm Or Customized
Loading Capacity 30-80Tons
Tire 12R22.5, 12units
Rim 9.00-22.5, 12units
Axles 3 Units BPW or FUWA brand
King Pin 3.5 inch JOST Brand
Brake System WABCO Valve and relays/ABS
Landing Gears JOST Landing gear
Susension Mechanical spring suspension/Air Suspension
Electrical 24 V
Light LED light ( speically intended for africa market)
Container lock 12 units

50Tons Cargo Fence semi trailers.

Top - Class Steel Frames 3 Axles Side Wall Semi Trailer With Advanced LED Light

60Tons Cargo Fence semi trailers.

Top - Class Steel Frames 3 Axles Side Wall Semi Trailer With Advanced LED Light
