2017 3 Axles Bulk cement tanker trailers compressor and diesel engine 55CBM
2017 3 Axles Bulk cement tanker trailers compressor and diesel engine 55CBM
2017 3 Axles Bulk cement tanker trailers compressor and diesel engine 55CBM
2017 3 Axles Bulk cement tanker trailers compressor and diesel engine 55CBM
2017 3 Axles Bulk cement tanker trailers compressor and diesel engine 55CBM
2017 3 Axles Bulk cement tanker trailers compressor and diesel engine 55CBM
2017 3 Axles Bulk cement tanker trailers compressor and diesel engine 55CBM
2017 3 Axles Bulk cement tanker trailers compressor and diesel engine 55CBM
Specifications
Brand Name :
FUDENG Brand
Model Number :
Bulk cement tanker trailer
Certification :
CCC, CE, SGS, BV,ADR
Place of Origin :
Shandong China(Mainland)
MOQ :
One Unit Bulk cement tanker tailer
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500Units per Month
Delivery Time :
20-30days after Deposit
Packaging Details :
Shipping by the Bulk cargo transportation
Product name :
Bulk cement tanker trailer
Loading capacity :
55CBM
Axles :
Fuwa/BPW/Chinese brand
Color :
Customized
Size :
10500*2500*4000 Or Customized
Material :
Reinforced Steel
Use :
Bulk Cement Transporters
Tank Thickness :
6mm Tank Thickness, Optional
Price :
negotiation
Description

2017 3 Axles Bulk cement tanker trailers compressor and diesel engine 55CBM

Features of Bulk Cement Tanker Trailer:

1. Steel structure: Steel frames are built with top-class hot rolled or rolled steel plate, automatic welded longitudinal beam and adopting advanced sanding and painting process as preliminary treatment.

2. Different types of suspension are designed for various operating condition: Bogie suspension; Air suspension; Mechanical suspension.

3. Lamp assembly uses advanced LED light, top quality PC and cast wire harness in dual circuit design.

4. Fluidized bed design is reasonable, the air compressor and the perfect match of tank; Residual rate is low, safety performance is high, easy to operate; Good performance of simple structure, convenient maintenance, vulcanization.

5.Working pressure 0.2Mpa, Discharge speed 1.2-1.5t/mm, Residual rate≤2‰,Discharge height≥25m.

Specification:

Product Name 3 Axles Bulk cement tanker trailers
Model GJC9400GYY
Brand Name SPECIAL TRAILER
Total Size (L×W×H)(mm) 11500x2500x3700mm
Internal size(mm) 11200x2495x2050mm
Volume 50 tons
Curb weight(kg) 9500
Tank body Q235/5mm steel
End plate Q235/6mm steel sheet
Compartment 1 Pcs
Manhole cover 2 Pcs 500mm manhole cover
Discharge valves 1 Pcs
Air compressor 37 KW,0.2Mpa. 1000r/Min(12m3/minute) Bohai brand
Engine Diesel engine Weichai brand model:4102
Handrail 1 pieces on the top of the tanker body
Ladder 1 piece, in the back of the tanker body
Leaf Spring 10/10/10
Axle 3 axles, 13ton/axle
Axle brand FUWA brand or BPW brand
Wheel Base(mm) 6950+1310+1310
Suspension Mechanical suspension or air suspension
Support leg Factory standard Brand 28T,two speed landing gear
King pin JOST Brand 50# or 90#
Tire 1100R20 12 pieces
Rim 9.0-20 12 pieces
Brake chamber 6 double chamber
Voltage 24V
Receptacle 7 ways (7 wire harness)
Light LED light
Tool box 1 Pcs
Spare tire carrier 1 Pcs
Painting Optional(QICAI brand)
Delivery time 20 working days after receive the deposit

35CBM Bulk cement tanker trailers.

2017 3 Axles Bulk cement tanker trailers compressor and diesel engine 55CBM

40Tons Bulk cement tanker trailers.

2017 3 Axles Bulk cement tanker trailers compressor and diesel engine 55CBM

Factory Overview.

2017 3 Axles Bulk cement tanker trailers compressor and diesel engine 55CBM

Welcome to visit our factory!
