Bomb Cart 40ft Container Trailer , Double / Tri Axle Container Chassis
Bomb Cart 40ft Container Trailer , Double / Tri Axle Container Chassis
Bomb Cart 40ft Container Trailer , Double / Tri Axle Container Chassis
Bomb Cart 40ft Container Trailer , Double / Tri Axle Container Chassis
Specifications
Brand Name :
Fudeng
Model Number :
SDFD1705 chassis trailer
Certification :
CE, ISO, CCC, SGS, ADR
Place of Origin :
Shandong, China
MOQ :
1 set
Payment Terms :
L/C, T/T or negotiate
Supply Ability :
600 sets per month
Delivery Time :
25-40 days after 30% deposit
Packaging Details :
Paint and wax spraying
Material :
Carbon Steel
Usage :
Transport 20ft And 40ft Container
Color :
White, Yellow, Red, Green, Blue Customized
Pattern :
Fudeng Logo Or As Customer's Request
Suspension :
Mechanical Or Air Suspension
Capacity :
30-50 Ton Available
Axle :
Fuwa or BPW brand
Conditions :
New
Tires :
12R22.5 Vacuum Tire / 11.00R20
Price :
negotiation
Description

40ft bomb cart chassis trailer 2 axle 3 axle handling containers within the port

With over 30 years experience in the design and building of container chassis, you can depend us to help you find the best solution for your application. Whether its standard, high payload or custom chassis, expect to receive the expert advice and personal service that you deserve no matter how big or small your need might be. And if new is not what you are looking for, we can offer used chassis too. Just check our Listing or contact us to check for availability!

Chassis trailer specification
Dimension 12.5m×2.5m×1.7m (Outside)
Payload 35T-75T
Tare weight About 4.5T--8.5T
Chassis
Frame Welding design or Special design I beam, connected by bolts and nuts, Q345B carbon steel material
Frame Beam Upper and lower plate is20mm,middle is10mm.height is 500 mm
Frame Floor The Thickness is 3-8 mm flat bed
Axle 2 or 3 axles, BPW/FUWA/HUAJING brand
Landing Gear JOST (D200T)or CHINA BRAND 28T
King Pin JOST 2.00 or 3.5 inch bolt-in king pin
Suspension Mechanical suspension/Germany or America type/air suspension
Leaf Spring 90mm(W)*13mm(T)*10 Layer/90mm(W)*16mm(T)*10 Layer/ 100mm(W)*16mm(T)*10 Layer
Pneumatic Braking System WABCO RE 6 relay valve; Spring brake chamber (TKL brand); one piece of 45L air tanks.
Rim 8.5-20,9.0-20,8.25-22.5,9.0-22.5 optional
Tire 11.00R20,12.00R20,11R22.5,12R22.5,315/80R22.5 Tire optional
ABS Optional
Accessories One standard tool box
Voltage 24V
