Low platform truck trailer low loader semi trailer 3 axle 50 ton
Low platform truck trailer low loader semi trailer 3 axle 50 ton
Low platform truck trailer low loader semi trailer 3 axle 50 ton
Low platform truck trailer low loader semi trailer 3 axle 50 ton
Specifications
Brand Name :
Fudeng
Model Number :
SDFD1702 low bed trailer
Certification :
CE, ISO, CCC, SGS, ADR
Place of Origin :
Shandong, China
MOQ :
1 set
Payment Terms :
L/C, T/T
Supply Ability :
600 sets per month
Delivery Time :
25-40 days after 30% deposit
Packaging Details :
Paint and wax spraying
Price :
negotiation
Material :
Carbon Steel
Usage :
Transport heavy machine
Color :
White, yellow, red, green, blue customized
Platform :
3mm - 8 mm
Suspension :
Mechanical or air suspension
Capacity :
50 ton available
Axle :
Fuwa or BPW or Chinese famous brand
Landing gear :
Standard 28 Ton
Description

Low platform truck trailer low loader semi trailer 3 axle 50 ton

3 AXLE SEMI LOW LOADER TRAILE


Capacity:

40.000 Kg - 70,000 Kg "max"

Type:

3 axle Semi Low Loader (Flat platform semi low loader trailer)

(Option: Extendable semi low loader trailer)

Weight:

10,500 Kg – 14,000 Kg

Axle Unit:

3 Units (For tires 12 Semi Low Loader sprung suspension gooseneck semi low loader trailer)

(Options: self-steering & hydraulic steering axles groups)

​Tire Unit And Dimension:

It is produce according to capacity or design. 11R20, 11 R 22.5" or 12 R 22.5"

Semi Low loader Trailer Chassis:

Semi Low Loader has been produced in welding constructions with gas metal arc welding as "I" crossing from high resistant steel considering overloads proper to capacity and intended usage.

Specifications
Dimension 13m×3m×1.7m (Outside)
Payload 40 - 80 ton customized
Tare weight About 11T
Bottom Platform 4mm thick checkered plate or flat plate
Chassis
Frame Welding design or Special design I beam, connected by bolts and nuts, Q345B carbon steel material
Frame Beam Upper and lower plate is 16 mm, middle is 8mm.height is 500 mm
Axle 3 axles 13T FD brand
Landing Gear Standard 28T JOST Brand
King Pin 2.00 or 3.5 inch bolt-in king pin JOST Brand
Suspension Mechanical suspension
Leaf Spring 90mm(W)*16mm(T)*10 Layer
Pneumatic Braking System 6 relay valve; Spring brake chamber (TKL brand) WABCO brand
Rim 9.0-20 optional
Tire 11.00R20 12pcs
Accessories One standard tool box
Voltage 24V
Packing and shipping
Painting Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Shipping Terms By Bulk Cargo/RORO


Low platform truck trailer low loader semi trailer 3 axle 50 ton

AREAS OF USE

The low bed trailer is suitable for the transport of:

  • Construction machines (excavation and road construction, recycling,...)
  • Forestry machines (harvester, skidder, forwarder,...)
  • Farming machines (tractors, combine harvesters,...)
  • Wind power plants (tower segments, generators, rotor or turbine blades)
  • Structural elements (steel and concrete elements)
  • Industrial parts (transformers, crane-loaded goods,...)
  • Lifting vehicles (lifting platforms, fork-lift trucks,...)
  • Crane systems (cranes, crane weights, crane components)
  • Conveying and crushing systems (demolition and recycling industry)
  • Track-guided vehicles (trams, locomotives, wagons)
  • Bulky goods, long materials and heavy loads

Low platform truck trailer low loader semi trailer 3 axle 50 ton

Welcome to contact us to get more information.
