80 Tons Bulk Cement Tanker Trailer Mobile Horizontal Cement Fly Ash Silo Semi Trailer
80 Tons Bulk Cement Tanker Trailer Mobile Horizontal Cement Fly Ash Silo Semi Trailer
80 Tons Bulk Cement Tanker Trailer Mobile Horizontal Cement Fly Ash Silo Semi Trailer
80 Tons Bulk Cement Tanker Trailer Mobile Horizontal Cement Fly Ash Silo Semi Trailer
Specifications
Brand Name :
Fudeng
Model Number :
FDZH110301
Certification :
CCC, CE, SGS, BV
Place of Origin :
Shandong, China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
900 sets per month
Delivery Time :
20 days after deposit
Packaging Details :
Bulk cargo ,RORO
Tank Thickness :
5mm
End plate Thickness :
6mm
Air Compressor :
FUDA
LOGO :
As Customers′ Request
Kingpin :
Jost 2" or 3.5"
Diesel Engine :
Weichai brand
Load Capacity :
85ton
Tire model :
1200R20 or 318/80R22.5 ,1200R24
Cabins :
Double cabins
Axle :
3 axle , FUWA or BPW 20tons
Description

80 tons Cement Tanker Trailer , 3 axles Mobile Horizontal Cement Fly Ash Silo Semi Trailer for Sale

Main Features:

Using fully automatic computer CAD design techology, tanks using automatic longitudinal/ring to the welding seam is firm and level off, can be independent warehouse storage, shipment different abrasive materials, unloading speed, low residual rate, safety performance is high, easy to operate.

Shape is round or V tanks, W tankes , material can choose carbon steel, stainless steel, aluminum alloy. Inside the bag or fluidized bed or MIZIXING fluidized bed.

Good perforance of simple structure, convenient maintenance, vulcanization.Can choose air compressor direct drive transmission shaft(optional belt drive and motor drive)

Technical Index: Under the condition of working pressure of 0.2 Mpa, discharging speed is 1.2 to 1.5 T/mm residual rate of 2‰ or less,under certain conditions, the discharging height 25 m or more.

80 Tons Bulk Cement Tanker Trailer Mobile Horizontal Cement Fly Ash Silo Semi Trailer

80 Tons Bulk Cement Tanker Trailer Mobile Horizontal Cement Fly Ash Silo Semi Trailer


Specification

Dimension: 1300*2500*4000mm
Tank Body
Tank thickness 5 mm
Front & end plate 6 mm
Tank rated pressure 0.2Mpa
Discharging System
Diesel Engine Model 4102 Diesel
Air Compressor 12 m³ , double cylinders compressor
Discharging valve 4 inch butterfly valve
Discharging pipe 1pcs, 8m/each
Manholes 3 pcs
Trailer Chassis
Main Beam Welded design,
Axles 3 axles BPW axles
Landing gear 28T ,JOST
Kin pin 3.5 inch bolt-in king pin
Suspension Mechanical suspension
Tire 12.00R24 , 12 pcs
Braking system WABCO emergency valve;
Electrical system Voltage: 24V
Tool box & tire carrier One tool box , 2 pieces tire carrier
Light & reflector Rear light, rear reflector, turn indicative light, side reflector,fog lamp,number plate light


Details


1 . Strength design for internal support structure can make the tank body stronger and more durable.

80 Tons Bulk Cement Tanker Trailer Mobile Horizontal Cement Fly Ash Silo Semi Trailer

2 . The bulk cement tanker semi trailer with the Wechai diesel engine and air compressor ,can have a longer service life .

80 Tons Bulk Cement Tanker Trailer Mobile Horizontal Cement Fly Ash Silo Semi Trailer


Hello friend , I don't know whether you have imported any truck trailer form China , but I think you made the right choice ,if you coming to us .our factory mainly do this business for over 20 years ,so if you need like that , just tell me your requirements , i can send our reference price to you .
