40M3 Bulk Cement Tanker Trailer 3 Axles With Air Compressor And Diesel Engine
40M3 Bulk Cement Tanker Trailer 3 Axles With Air Compressor And Diesel Engine
40M3 Bulk Cement Tanker Trailer 3 Axles With Air Compressor And Diesel Engine
40M3 Bulk Cement Tanker Trailer 3 Axles With Air Compressor And Diesel Engine
Specifications
Brand Name :
Fudeng
Model Number :
SDFD201708
Certification :
CE, ISO9001, CCC
Place of Origin :
Shandong, China
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T, L/C or negotiate
Supply Ability :
600 sets per month
Delivery Time :
25-40 days after 30% deposit
Packaging Details :
Paint and wax spraying
Material :
Carbon steel
Color :
Fudeng logo or as customer's request
Volume :
25 cbm - 35 cbm
Suspension :
Mechanical or air suspension
Axle :
FUWA, BPW or Chinese brand
Usage :
Transport cement, powder, silos
Landing gear :
Double speed 28 ton
Shape :
V shape or W shape
Description

40 m3 Cement bulker Tank Trailer 3 axles with air compressor and diesel engine

Widely praised as the industry’s most cement dry bulk trailers, Fudeng Trailer offers vessel integrity, low tare weights, high efficiency, long wear, easy cleanout and Fudeng Trailer craftsmanship throughout, to keep your operation running at maximum efficiency.

Fudeng Trailer durability—for the most challenging dry bulk loads and applications
Easy cleanout—for efficient product changeover
High capacity/low tare weights—for maximum productivity
3-A Sanitary compliance—the highest standard for food grade transport
High loading/unloading rates—for maximum throughout

Loading capacity only a design capacity, could be change as per country road regulations. Different capacity trailers could be customize.

Including:

Spear Wheel with Carrier.
Rear bumper guard.
Safety crash bar on both side.
Safety luminous fitting.
Dia 4″x10 ft. hose with female coupling at both ends
Cat walk, Apron & Access ladder
Tool box (space for tool &accessories)

Bulk Cement Tank Trailer Specifications
Tank Body
Shape V shape customized
Dimension 13000*3990*2500mm
Capacity 25 - 35 cbm
Tanker Body 5mm Q345B
End Plate 6mm Q345B
Manhole Cover 2 or 3 pieces
Air Compressor Wuhu Fuda 12 cbm double-cylinder, Working pressure 0.2 MPa, Testing pressure 0.3 MPa
Diesel Engine Weichai 4102 or 4105
Chassis
Main Beams T700 high- insensitive steel Upper plate is 14mm and lower is 16mm,middle is 8mm. height is 500 mm
Axle 2 or 3 axles, 13T American type, 16T brake block, Fuwa brand
Landing Gear Standard 28T Jost brand
King Pin 5.0(2 inch)/9.0(3.5 inch) bolt Jost brand
Suspension Mechanical suspension
Leaf Spring 90mm(W)*16mm(T)*10 Layer
Pneumatic Braking System 6 air chamber, 3 axles synchronization Webco brand
Rim 9.00-22.5/8.00-22.5/8.5-22.5
Tire 11.00R22.5/12.00R22.5 Triangle brand
ABS KEMI Optional
Accessories 2 standard tool box Optional
Spare Tire Rack 2 Optional
Radiator Optional

40M3 Bulk Cement Tanker Trailer 3 Axles With Air Compressor And Diesel Engine

40M3 Bulk Cement Tanker Trailer 3 Axles With Air Compressor And Diesel Engine

Welcome to contact us for more information!
