SINOTRUCK Howo Vacuum Tank Truck , 309KW Power Tanker Truck Trailer
SINOTRUCK Howo Vacuum Tank Truck , 309KW Power Tanker Truck Trailer
SINOTRUCK Howo Vacuum Tank Truck , 309KW Power Tanker Truck Trailer
SINOTRUCK Howo Vacuum Tank Truck , 309KW Power Tanker Truck Trailer
SINOTRUCK Howo Vacuum Tank Truck , 309KW Power Tanker Truck Trailer
SINOTRUCK Howo Vacuum Tank Truck , 309KW Power Tanker Truck Trailer
Specifications
Brand Name :
HOWO Brand
Model Number :
Tractor head trucks
Certification :
CE/ISO/BV/ADR/DOT
Place of Origin :
Shandong China(Mainland)
MOQ :
One Unit Tractor head trucks
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500Units per Month
Delivery Time :
20-30days after deposit
Packaging Details :
Nude package shipping by bulk cargo or Ro-Ro
Price :
negotiation
Condition :
New
Usage :
Tractor head trucks
Drive stype :
6x4
Brand name :
Howo brand
Color :
Customized
Power :
309KW
By wheel :
4 WD
Size :
6800*2496*3563 mm
Description

CHINA SINOTRUCK tank car Howo Vacuum Tank Truck Howo Truck tanker truck

FEATURES Tractor trailer trucks.

Luxurious, majestic and dynamic appearance.

--Latest international style cabin: Euro type cabin.

--Crystal and upright mounted headlamp

Reliable and high-security Design

--Lateral stability: Patent and tailored frame design

--Safety and reliability: New type break drum.

Low fuel consumption and high efficiency

--High efficiency Power-train: Optimized power transmission design

--Low wind resistance: Streamlined cabin design

Confortable

--Flat floor cabin, enlarge the driver’s space.

--Noise isolation technology

--Ergonomic trim and adjustable seats

--Tilted footstep on front bumper.

--Streamlined cabin design

--Ergonomic dashboard

Specification:

Representative Vehicle Model ZZ4257M3241V ZZ4257N3241V ZZ4257S3241V ZZ4257V3241V
Model HW79
Type High roof cab, double berth, up/down and front/back adjustable steering wheel ,VDO instrumentand control module, double-locking safety belt ,exterior sun visor
Model WD615.87 WD615.69 WD615.47 D12.42
Rated Power kW/rpm 213/2200 247/2200 273/2200 309/2000
Maximum Torque Nm/rpm 1160/1100-1600 1350/1100-1600 1500/1100-1600 1820/1100-1500
Displacement L 9.726 11.596
Type Six cylinders inline, supercharged intercooler .WD615 Engine two valve, supercharge postposition ,D12 Engine four valve ,central supercharger
Clutch Φ430 diaphragm spring clutch, Hydraulic control air assisted , WD615.47, D12.38 and D12.42 Engine standard 430A. WD615.69 standard 430B ,WD615.62,WD615.87 standard 430C
Transmission

SINOTRUK HW series 10 gears Transmission, main and auxiliary transmission structure ,main

Transmission with double counter shaft, auxiliary transmission with planetary reduction.

WD615.62,WD615.87 standard HW15710 ,WD615.69, Standard HW15710/RT11509C

WD615.47.D12.38 and D12.42 standard HW19710/HW19712
Front Axle HF7, rated load of 7t, disc-type or drum-type; heavy load with HF9 drum-type , rated load of 9t
Drive Axle ST16 double reduction, speed ratio :3.93;4.42;4.8; heavy load truck with HC16 double reduction , speed ratio: 4.42,4.8,5.73
Suspension Front and rear leaf spring suspension, front suspension with shock absorber , transverse stabilizer, rear suspension is disconnected type with transverse stabilizer.
Steering System ZF8098 steering gear , ZF steering oil pump , system pressure 18MPa
Braking System Service brake: dual-circuit air pressure brake : spring storage energy without air ; auxiliary brake :Engine exhaust braking ;standard ABS, Engine EVB is optional and optional auto clearance adjusting arm .
Electrical System voltage : 24V ;generator :1540W ; starter :24V, 7.5kW ; battery : 12V/165Ah, 2 pieces
Tyre 12.00R20; 12R22.5 is optional, 315/80R22.5 Tyre ;
Tank Volume L 400L ; 260L auxiliary fuel tank can be added
Kerb Weight (vehicle/chassis) kg 9210 9210 9210 9260
Gross Mass kg 25000 25000 25000 25000
External Dimension (L*W*H) mm 6800x2496x3563 6800x2496x3563 6800x2496x3563 6800x2496x3563
Wheel Base mm 3200+1350 3200+1350 3200+1350 3200+1350


Tractor Head Trucks Models.

371 Horse Power 20000 Litres Fuel Tank truck for sale

SINOTRUCK Howo Vacuum Tank Truck , 309KW Power Tanker Truck Trailer

Water tanker trucks.

We can according to your request to your request to design the litres for Tanker.

SINOTRUCK Howo Vacuum Tank Truck , 309KW Power Tanker Truck Trailer

Welcome to China and visit our factory. We believe your smart choice will be rewarded with good quality and competitive price.

Our company is manufacturer for semi trailer and we also can provide Sinotruck HOWO brand truck for you ,Semi trailer and truck all can provide with Customized service for you ,

We can provide all kinds of semi trailer for you Like Fuel Tank trailer , LPG Tank trailer,Bulk cement Tank trailer and so on .

1.Fuel Tank trailer : We can according to your request to design litres and compartment for you ;

2.LPG Tank trailer : The Tank body and other Specifications can adjust for you before production ;

3.Bulk cement Tank trailer : The Shape for Bulk cement Tank trailer we can design according to the cubic meters you need ;

If you are interested in other products in our company ,Welcome to inquiry more information anytime !

Welcome to visit our factory !
