Specifications
Brand Name :
DCM
Model Number :
OPEN，-Z，-RS，-RZ，-RSR
Certification :
ISO9001
Place of Origin :
China
MOQ :
Negotiated
Price :
Negotiated
Payment Terms :
Negotiated
Supply Ability :
Negotiated
Delivery Time :
Negotiated
Packaging Details :
Industrial Packing or Single Box, Cartoon,Pallet
Material :
GCr15
Precision Rating :
P0 P6 P5 ABEC-1 ABEC-3 ABEC-5
Clearance :
C0 C2 C3 C4 C5 C9
Vibration :
Z1 Z2 Z3 Z4 V1 V2 V3 V4
Number of row :
Single Row
Lubrication :
Grease or oil
Cage :
Steel Cage,Nylon,Brass
Package :
Original Package,Tube,Plastic bag+single box,Cartons
Description

Deep Groove Ball Bearings 6800 Series ID 10 - 300 mm Z1 Z4 V1 V4 P6 P5 Open ZZ 2RS High precision Long Life Low Noise

Features

Deep groove ball Bearings are used in automobile, tractor, machinery, motor, water pump, agricultural machinery and textile machinery. Its wide application, simple design, non - separation, suitable for high - speed, reliable operation, low maintenance costs.The tight consistency between deep raceway and groove and ball enables deep raceway ball bearings to withstand axial loads in both directions in addition to radial loads.Deep groove ball bearings have various types in structure, besides open type bearings, shields or seals at both sides can also be provided.

Product Specification

Bearing No. Structure Boundary Dimensions(mm) Basic Load Rating(kN) Weight(kg)
d D B rs min Cr Cor
61809 OPEN ZZ 2RS 45 58 7 0.3 4.65 4.32 0.04
61810 OPEN ZZ 2RS 50 65 7 0.3 6.6 6.1 0.043
61811 OPEN ZZ 2RS 55 72 9 0.3 9.1 8.4 0.07
61812 OPEN ZZ 2RS 60 78 10 0.3 9.1 8.7 0.093
61813 OPEN ZZ 2RS 65 85 10 0.6 11.9 11.5 0.13
61814 OPEN ZZ 2RS 70 90 10 0.6 12.1 11.9 0.138
61815 OPEN ZZ 2RS 75 95 10 0.6 12.5 12.8 0.147
61816 OPEN ZZ 2RS 80 100 10 0.6 12.7 13.3 0.155
61817 OPEN ZZ 2RS 85 110 13 1 19.2 19.8 0.245
61818 OPEN ZZ 2RS 90 115 13 1 19.5 20.5 0.258
61819 OPEN ZZ 2RS 95 120 13 1 19.8 21.3 0.27
61820 OPEN ZZ 2RS 100 125 13 1 20.1 22 0.303
61821 OPEN ZZ 2RS 105 130 13 1 20.3 22.7 0.312
61822 OPEN ZZ 2RS 110 140 16 1 22.5 24.5 0.509
61824 OPEN ZZ 2RS 120 150 16 1 24 28 0.529
61826 OPEN ZZ 2RS 130 165 18 1.1 24.2 28 0.775
61828 OPEN ZZ 2RS 140 175 18 1.1 39.2 46 0.784
61830 OPEN ZZ 2RS 150 190 20 1.1 49.1 57.1 1.11
61832 OPEN ZZ 2RS 160 200 20 1.1 45.2 55.1 1.18
61834 OPEN ZZ 2RS 170 215 22 1.1 51.2 63.3 1.65
61836 OPEN ZZ 2RS 180 225 22 1.1 62.3 75.9 1.62
61838 OPEN ZZ 2RS 190 240 24 1.5 75.1 91.6 2.1
61840 OPEN ZZ 2RS 200 250 24 1.5 74.2 91.2 2.18
61848 OPEN ZZ 2RS 240 300 28 2 98.5 137 4.48
61852 OPEN ZZ 2RS 260 320 28 2 101 148 4.84
61856 OPEN ZZ 2RS 280 350 33 2 133 191 7.2
61860 OPEN ZZ 2RS 300 380 38 2 166 233 10.3

DCM Deep Groove Ball Bearings 6800 61800 6900 61900Open 2RS Series Low Noise Tight Consistency

Application

DCM Deep Groove Ball Bearings 6800 61800 6900 61900Open 2RS Series Low Noise Tight Consistency

DCM Deep Groove Ball Bearings 6800 61800 6900 61900Open 2RS Series Low Noise Tight Consistency

Main Products

DCM Deep Groove Ball Bearings 6800 61800 6900 61900Open 2RS Series Low Noise Tight Consistency

Packaging & Shipping

DCM Deep Groove Ball Bearings 6800 61800 6900 61900Open 2RS Series Low Noise Tight ConsistencyDCM Deep Groove Ball Bearings 6800 61800 6900 61900Open 2RS Series Low Noise Tight Consistency

FAQ

Q1.Do you have MOQ?

Depends on different ideas, Can be negotiated.The larger the quantity is, the competitive the unit price will be.

Q2.Should the customer pay the delivery fee,How much is it?

For the delivery fee,many samples are be requested to be sent,so we must get delivery fee. If you tell me to use the appointed Express,you will give me your express account or you will pay according to the Express. If you do not request,I will choose a cheap one in China.

Q3.How about the after sale service?

1)We will always keep the quality the same as the buyer's samples and if there is something with the quality,we will make compensation for our customers.

2)We will suggest our packing and take charge in our packing,we will keep the goods safe in the delivery.

3)We will trace the goods from the production to selling,we will solve the problems in the selling for our customers.

Q4.When can I get a price?

We usually quote within 24 hours after we get your inquiry.

Q5: Are you a trade company or manufacturer?

We are a professional manufacturer with our own factory.
