Specifications
Brand Name :
DCM
Model Number :
Tapered Roller Bearings 33000 Series
Certification :
ISO9001
Place of Origin :
China
MOQ :
Negotiated
Price :
Negotiated
Payment Terms :
Negotiated
Supply Ability :
Negotiated
Delivery Time :
Negotiated
Packaging Details :
Industrial Packing or Single Box, Cartoon,Pallet
Material :
GCr15
Precision Rating :
P0 P6 P5 ABEC-1 ABEC-3 ABEC-5
Vibration :
V1 V2
Type :
Roller
Structure :
Taper
Cage :
Steel Cage
Application :
Automotive
Description

Tapered Roller Bearings 33000 Series ID 30 - 100 mm

Features

Tapered Roller Bearings are designed for using in a wide range of applications, including automotive, tractor, rolling mill, mining, metallurgical, plastic machinery,etc. This is a separable type of bearing. The inner ring (cone), along with the cage and rollers, is one assembly unit; the outer ring (cup) is the other assembly unit. This feature allows the bearings to be fitted separately and adjusted so that the optimum clearance or preload for each application is achieved.

Due to the inclined position of the tapered rollers, the contact lines between the rollers and raceways intersect at a common point on the axis of the bearing. The contact surfaces of the raceways and tapered rollers are modified to limit edge stresses. As a result of this modification and the large number of rollers, this bearing has high load-carrying capacity and is designed to carry axial and radial loads simultaneously. Since a single bearing of this type can only carry axial loads in one direction, the bearings are usually mounted in pairs.

DCM can produce high quality TRB as the customer requests.We are happy to produce further construction methods. Please do not hesitate to contact us for special bearing characters.We can also supply OEM service.

Product Specification

Bearing code Basic dimension Basic load rating Limiting Speeds Weight Caculation factor
d D B C T rmin nmin Cr Cor Grease Oil Wt e Y Yo
mm mm mm mm mm mm mm kN kN r/min r/min kg
33006 30 55 20 16 20 1 1 42 54 6700 9000 0.208 0.29 2.1 1.1
33007 35 62 21 17 21 1 1 49 65 5600 8000 0.267 0.31 2 1.1
33008 40 68 22 18 22 1 1 59 81.5 5300 7100 0.32 0.28 2.1 1.2
33009 45 75 24 19 24 1 1 69 99 4800 6300 0.414 0.29 2 1.1
33010 50 80 24 19 24 1 1 70.5 104 4300 6000 0.452 0.32 1.9 1
33011 55 90 27 21 27 1.5 1.5 91.5 138 3800 5300 0.657 0.31 1.9 1.1
33012 60 95 27 21 27 1.5 1.5 96 150 3600 5000 0.713 0.33 1.8 1
33013 65 100 27 21 27 1.5 1.5 97.5 156 3400 4500 0.76 0.35 1.7 0.95
33014 70 110 31 25.5 31 1.5 1.5 127 204 3000 4300 1.11 0.28 2.1 1.2
33015 75 115 31 25.5 31 1.5 1.5 133 220 3000 4000 1.18 0.3 2 1.1
33016 80 125 36 29.5 36 1.5 1.5 172 282 2800 3600 1.66 0.28 2.2 1.2
33017 85 130 36 29.5 36 1.5 1.5 180 305 2600 3600 1.75 0.29 2.1 1.1
33018 90 140 39 32.5 39 2 1.5 220 360 2400 3200 2.21 0.27 2.2 1.2
33019 95 145 39 32.5 39 2 1.5 231 389.9 2400 3200 2.26 0.28 2.2 1.2
33020 100 150 39 32.5 39 2 1.5 229.2 391.2 2200 3000 2.4 0.29 2.1 1.2
33021 105 160 43 34 43 2.5 2 256 435 2000 2800 3.03 0.28 2.1 1.2
33024 120 180 48 38 48 2.5 2 300 540 1800 2600 4.2 0.31 2 1.1
33026 130 200 55 43 55 2.5 2 395 715 1700 2200 6.25 0.34 1.8 0.97
33028 140 210 56 44 56 2.5 2 410 770 1600 2200 6.74 0.36 1.7 0.92
33030 150 225 59 46 59 3 2.5 435 805 1400 2000 8.07 0.36 1.7 0.9
33205 25 52 22 18 22 1 1 47.5 56.5 7500 10000 0.22 0.35 1.7 0.94
33206 30 62 25 19.5 25 1 1 70.5 75 6000 8000 0.343 0.34 1.8 0.97
33207 35 72 28 22 28 1.5 1.5 87.5 106 5300 7000 0.519 0.35 1.7 0.93
33208 40 80 32 25 32 1.5 1.5 113 126 4800 6300 0.701 0.36 1.7 0.92
33209 45 85 32 25 32 1.5 1.5 115 150 4300 6000 0.789 0.39 1.6 0.86
33210 50 90 32 24.5 32 1.5 1.5 119 160 4000 5300 1.17 0.41 1.5 0.8
33211 55 100 35 27 35 2 1.5 143 196 3600 5000 1.17 0.4 1.5 0.8
33213 65 120 41 32 41 2 1.5 183 280 3000 4000 2.02 0.39 1.5 0.85
33215 75 130 41 31 41 2 1.5 190.9 315.2 2800 3800 2.215 0.43 1.4 0.77
33216 80 140 46 35 46 2.5 2 256 385 2600 3400 2.93 0.43 1.4 0.78
33217 85 150 49 37 49 2.5 2 281 415 2400 3200 3.57 0.42 1.4 0.79
33220 100 180 63 48 63 3 2.5 410 635 2000 2600 6.76 0.4 1.5 0.82
306/47 47 100 43 37 43 1.5 1 145 205 5300 6700 1.661 0.3 1.9 1.1

33000 Tapered Roller Bearings , V1 V2 Pressure Roller Bearings ID 30 - 100mm33000 Tapered Roller Bearings , V1 V2 Pressure Roller Bearings ID 30 - 100mm33000 Tapered Roller Bearings , V1 V2 Pressure Roller Bearings ID 30 - 100mm

Application

  • Logistic Transport Facilities
  • Automation Technology
  • Machine Tools
  • Aerospace Industry
  • Mechanical Engineering
  • Industrial Robots
  • Textile Machinery
  • Automotive Industry
  • Construction Machinery
  • Electric Motors
  • Gearboxes

33000 Tapered Roller Bearings , V1 V2 Pressure Roller Bearings ID 30 - 100mm

Main Products

33000 Tapered Roller Bearings , V1 V2 Pressure Roller Bearings ID 30 - 100mm

Packaging & Shipping

33000 Tapered Roller Bearings , V1 V2 Pressure Roller Bearings ID 30 - 100mm

33000 Tapered Roller Bearings , V1 V2 Pressure Roller Bearings ID 30 - 100mm

FAQ

Q1.Do you have MOQ?

Depends on different ideas, Can be negotiated.The larger the quantity is, the competitive the unit price will be.

Q2.Should the customer pay the delivery fee,How much is it?

For the delivery fee,many samples are be requested to be sent,so we must get delivery fee. If you tell me to use the appointed Express,you will give me your express account or you will pay according to the Express. If you do not request,I will choose a cheap one in China.

Q3.How about the after sale service?

1)We will always keep the quality the same as the buyer's samples and if there is something with the quality,we will make compensation for our customers.

2)We will suggest our packing and take charge in our packing,we will keep the goods safe in the delivery.

3)We will trace the goods from the production to selling,we will solve the problems in the selling for our customers.

Q4.When can I get a price?

We usually quote within 24 hours after we get your inquiry.

Q5: Are you a trade company or manufacturer?

We are a professional manufacturer with our own factory.
