205PPB7 RSR Agricultural Machinery Bearing , Z1 Z2 Single Row Bearing
205PPB7 RSR Agricultural Machinery Bearing , Z1 Z2 Single Row Bearing
205PPB7 RSR Agricultural Machinery Bearing , Z1 Z2 Single Row Bearing
205PPB7 RSR Agricultural Machinery Bearing , Z1 Z2 Single Row Bearing
205PPB7 RSR Agricultural Machinery Bearing , Z1 Z2 Single Row Bearing
205PPB7 RSR Agricultural Machinery Bearing , Z1 Z2 Single Row Bearing
Specifications
Brand Name :
DCM
Model Number :
OPEN，-Z，-RS，-RZ，-RSR
Certification :
ISO9001
Place of Origin :
China
MOQ :
Negotiated
Price :
Negotiated
Payment Terms :
Negotiated
Supply Ability :
Negotiated
Delivery Time :
Negotiated
Packaging Details :
Industrial Packing or Single Box, Cartoon,Pallet
Material :
GCr15
Precision Rating :
P0 P6 P5 ABEC-1 ABEC-3 ABEC-5
Clearance :
C0 C2 C3 C4 C5 C9
Vibration :
Z1 Z2 Z3 Z4 V1 V2 V3 V4
Number of row :
Single Row
Lubrication :
Grease or oil
Cage :
Steel Cage,Nylon,Brass
Feature :
Long Life,High Speed,low noise
Description

DCM Bearings For Agricultural Machinery

Agricultural machinery
Agricultural machinery including combine harvester, tractor, seeder, transplanter, tillage machine, etc., works under a bad environment with a lot of dust, mud and water. Only used during slack time, they usually don’t have a high limit speed, but require bearings to have excellent sealing performance. To meet the requirements of harsh working conditions, DCM can provide various rolling bearings and technical solutions for different sealing structures.

Solutions
Sealing: multi-lip seal structure designed to prevent external impurities;

Lubrication: the use of high-quality grease against extreme pressure, water vapor to extend the bearing’s life;

Process optimization: special heat treatment and grinding process to improve the material properties and the microscopic morphology of bearing parts and to prolong the bearing life.

Strengths

DCM offers complete product specifications, thoughtful service, bringing you the great convenience to choose bearings;

DCM provides timely technical support and personalized services to help speed up your project development;

High-quality and cost-effective products help you reduce procurement costs.

Product Specification

205PPB7 RSR Agricultural Machinery Bearing , Z1 Z2 Single Row Bearing

Bearing No. Type Bearing Bore Size Outside Dia. Ring Width
A B Inner Ring Outer Ring
(in.) (mm) (in.) (mm) (in.) (mm) (in.) (mm)
205PPB7 1 0.9375 23.813 2.0472 52 1.3748 34.92 0.591 15
W208PPB7 1 1.188 30.175 3.1496 80 1.189 30.2 0.709 18
W208PP10 4 1.5005 38.113 3.1496 80 1.691 42.96 0.827 21
W208PPB23 1 1.5005 38.113 3.1496 80 1.691 42.96 1.189 30.2
W209PPB2 2 1.7717 45 3.346 85 1.189 30.2 1.189 30.2
W209PPB4 2 1.535 39 3.346 85 1.189 30.2 1.189 30.2
W210PP2 5 1.938 49.225 3.5433 90 1.189 30.2 1.189 30.2
W210PPB2 2 1.938 49.225 3.5433 90 1.189 30.2 1.189 30.2
W211PP2 5 2.188 55.575 3.937 100 1.313 33.34 1.313 33.34
W211PPB2 2 2.188 55.575 3.937 100 1.313 33.34 1.313 33.34

Bearing No. Type Square Shaft Size Square Bore Size Outside Dia. Ring Width
B Inner Ring Outer Ring
(in.) (mm) (in.) (mm) (in.) (mm) (in.) (mm)
W208PPB13 1 7/8 23.117 3.1496 80 1.437 36.5 0.709 18
W208PPB6 1 1 26.162 3.1496 80 1.437 36.5 0.709 18
W208PP5 4 1-1/8 29.972 3.1496 80 1.437 36.5 0.709 18
W208PPB5 1 1-1/8 29.972 3.1496 80 1.437 36.5 0.709 18
W208PP8 4 1-1/8 29.972 3.1496 80 1.437 36.5 1.189 30.2
W208PPB8 1 1-1/8 29.972 3.1496 80 1.437 36.5 1.189 30.2
W208PPB11 3 7/8 23.117 3.376 85.75 1.437 36.5 1.189 30.2
W208PPB12 3 1-1/8 29.972 3.376 85.75 1.437 36.5 1.189 30.2
W209PPB5 1 1-1/4 32.766 3.346 85 1.437 36.5 1.189 30.2
W210PP4 5 1-1/8 29.972 3.5433 90 1.189 30.2 1.189 30.2
W210PPB4 2 1-1/8 29.972 3.5433 90 1.189 30.2 1.189 30.2
W211PP3 5 1-1/2 38.89 3.937 100 1.313 33.34 1.313 33.34
W211PPB3 2 1-1/2 38.89 3.937 100 1.313 33.34 1.313 33.34
W211PP5 4 1-1/2 38.89 4 101.6 1.75 44.45 1.438 36.52
W211PPB6 3 1-1/2 38.89 4.0772 103.56 1.75 44.45 1.438 36.52

Features

1) Series available: FDxxx, STxxx, GNExxxKRRB, xxxKRRB, xxxKPPB, WxxxPP, WxxxPPB, GWxxxPP, GWxxxPPB, GUWxxxPPB, PFxxx, SBXxxx, XFxxx, WIRxxx

2) Material: Beaing Steel, Stainless steel

3) Cage: PA66, Optional

4) Steel Ball: GCR15

5) Shaft: GCr15

6) Outer ring: Gcr15

7) Axial clearance: optional

8) Radial clearance: optional

9) Static Load: optional

Series of the disc harrow bearings

1)Round bore

2)Square bore

3)Hex bore

4)Disk harrow units

Advantage

1)Low noise precision bearings
2)Strict quality control system with perfect QC facilities
3)Prompt delivery and good service

Application

  • Combine-harvester,

  • tractor,

  • planter,

  • rice transplanter

205PPB7 RSR Agricultural Machinery Bearing , Z1 Z2 Single Row Bearing
