Truck spray painting booth /spray booth painting cabinet TG-18-50
Truck spray painting booth /spray booth painting cabinet TG-18-50
Specifications
Brand Name :
TARGET
Model Number :
TG-18-50
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1set
Price :
$30000--60000
Payment Terms :
T/T, L/C
Supply Ability :
1000set/month
Delivery Time :
7--10 days
Packaging Details :
Standard export package
Description

Truck spray painting booth /spray booth painting cabinet TG-18-50

Truck spray painting booth /spray booth painting cabinet TG-18-50

Specifications:

Spray Booth Truck Diesel Burner TG-18-50
Inside dimension 18000×5000×5000mm(L×W×H)
Outside dimension 18144×6896×5600mm(L×W×H)
Wall panel Profiled bar beams in the roof to strengthen the room body; wall panel thickness: 70mm, width: 710mm, tongue and groove structure, with. EPS insulation inside, colour: white.
Doors Main door: Folding door, 4 folds, 4000×4500mm(W×H),with galvanized steel frame, with polystyrene(EPS) inside, color: blue Escape door: 2 units, 800x2000mm(W×H) /PC, colour: white.
Basement without basement, 2 rows of pits in the ground for exhaust air, dimension of each pit is 16100×760mm(L×W), with galvanized grilles made by twisted steel and flat bar above.
Intake air system 6×5.5KW double-intake centrifugal fans for intake air,Model YDW4.5S, total air capacity: 93000m3/h
Exhaust air system 3×11KW double-intake centrifugal fans for exhaust air, with motor outside, belt-drive, model TAE-630H, Total air capacity: 84000m3/h.
Damper actuates Pneumatic damper actuates from spraying to baking cycle, manual dampers for exhaust air
Heating system 3 units RIELLO RG5S diesel burners, stainless steel heat exchanger, Max. Heating productivity: 780000 Kcal/h, Max. Work temperature: 80℃
Filter system Pre-filter, ceiling filter, exhaust fibreglass filter, activated carbon filter.
Filtering area 75M2
Lighting system

Ceiling Lights: 24Units×4Pcs=96Pcs×36W, Side Lights: 28Units×4Pcs=112Pcs×36W,

with electronic ballasts, up and down interleaving installation.
Control system Spraying, heat spraying, baking, baking, time setting, lighting switch, failure indicator, thermostat, power supply switch, emergency stop, ampere meter, voltmeter, hours meter, temperature limit controller, pressure gauge. Exhaust reduction voltage motor start
Total power 75.5KW

Our services:

1. OEM ODM service.

2. Customized service: the color and size of the product can be customized.

3. Two Years Quality warrant service, during the period spare part supplied free if you pay for shipping.

4. Professional team supply service for life long time.

FAQ:

1. Are you trading company or manufacturer?

We are powder coating line /car and furniture spray booth / frame machine manufacturer from Shandong province and we have trade team.

2. how about your delivery time for one model?

Usually one standard model need 7 workdays after confirm order. up to 15m length, it need 15--20 days.
3. how many color do you have?
We will customize the color accorditing to your requirements. Any color you requirements.
4. If customer have some special requirement, can you change your standard model?

Yes, if our standard model can't meet your requirement, we can design it for you according to your need.


TARGET Equipment is your best choose!
