Dry type paint booth dry spray booth for wood furniture TG-100B
Dry type paint booth dry spray booth for wood furniture TG-100B
Specifications
Brand Name :
TARGET
Model Number :
TG-100B
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1set
Price :
$20000---50000
Payment Terms :
T/T, L/C
Supply Ability :
1000 set/month
Delivery Time :
5--10 days
Packaging Details :
Standard export package
Description

Dry type paint booth dry spray booth for wood furniture TG-100B

Dry type paint booth dry spray booth for wood furniture TG-100B

Dry type paint booth dry spray booth for wood furniture TG-100B

Dry type paint booth dry spray booth for wood furniture TG-100B

Furtinure Spray-Baking booth TG-100B
Outside Dimension (L×W×H) 20000×5000×3000mm
Painting Room Dimension (L×W) 4900×4900mm
Drying Room Dimension (L×W) 14950×4900mm
Incoming Door Dimension (W×H) 1900×2000mm
Delivery Door Dimension (W×H) 1900×2000mm
Air Capacity 18000 M³/h
Air Speed 0.25-0.3 m/s
Ventilation Rate 255 Times/Hour
Wall Panels 50mm thick EPS heat preservation wall panels
Grilles 40mm×3mm flat iron,10#channel steel
Lighting

spray booth:18units×36w

baking booth:12units×36w Illuminance exceeding 450LUX, non explosive
Infrared Heating Tubes 30units×1kw carbon fiber far-infrared heating tubes, non explosive
Generator Setting Type upper intake air
Intake Air Fan 2×4KW double-intake centrifugal fans, air capacity:18000m³/h,
Water Curtains dimension:3000×400×1500mm(L×W×H),stainless steel.
Water Pump brand:Lailibao, capacity:7m³/h, lift:18m, rotate speed:2860rotate/m power:750W 380V/50HZ
Filter System pre-filter, high efficiency filter(ceiling filter)
Total Power(KW) 39Kw
