Fixed Install HD LED Display P10 SMD Full Color Outdoor Panel 10000 Pixel /㎡ Pixel Density
Fixed Install HD LED Display P10 SMD Full Color Outdoor Panel 10000 Pixel /㎡ Pixel Density
Fixed Install HD LED Display P10 SMD Full Color Outdoor Panel 10000 Pixel /㎡ Pixel Density
Fixed Install HD LED Display P10 SMD Full Color Outdoor Panel 10000 Pixel /㎡ Pixel Density
Fixed Install HD LED Display P10 SMD Full Color Outdoor Panel 10000 Pixel /㎡ Pixel Density
Fixed Install HD LED Display P10 SMD Full Color Outdoor Panel 10000 Pixel /㎡ Pixel Density
Fixed Install HD LED Display P10 SMD Full Color Outdoor Panel 10000 Pixel /㎡ Pixel Density
Fixed Install HD LED Display P10 SMD Full Color Outdoor Panel 10000 Pixel /㎡ Pixel Density
Specifications
Brand Name :
TBC
Model Number :
P10 (E10-A)
Certification :
CE-EMC, CE-LVD, RoHS, ETL, FCC
Place of Origin :
Shenzhen,China
MOQ :
5SQM
Price :
Negotiable
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
10000 SQM Per Month
Delivery Time :
7-15 Working Day
Packaging Details :
Wooden Case / Flight Case
Pixel Pitch :
10mm
Cabinet Size :
960*960*150mm
Brightness :
6000nit
Resolution :
96*96 Pixel For Each Cabinet
Pixel Density :
10000 Pixel/㎡
Cabinet Weight :
53KG
Description

Outdoor fixed install P10 SMD full color Outdoor HD LED Display Panel




Product Parameters:

Pixel Pitch

10mm real-SMD

BRIGHTNESS

6000Nit

MODULE SIZE

960 x 960 x 150mm

MODULE WEIGHT

53KG

MODULE RESOLUTION

96 x 96 Pixel

PIXEL DENSITY

10000Pixel/㎡

VIEWING ANGLE

160° / 160°

DIGITAL PROCESSING

16 bit

FRAME RATE

50/60 Hz

REFRESH RATE

1920 Hz

POWER INPUT

AC 110/220v, 50/60Hz

POWER CONSUMPTION

350 W/㎡(AVG) ; 1000 W/㎡(Max)

INGRESS PROTECTION

FRONT:IP65 ; REAR:IP54

















Fixed Install HD LED Display P10 SMD Full Color Outdoor Panel 10000 Pixel /㎡ Pixel Density

FAQ :

Q1: What's the warranty of your LED Display Screen ?

A1: We have a 3-year warranty for our led display screen, and 100,000 hours life span of the led lamps.

Q2: What about your Pre-sale service and After-sale service?

A2: For Pre-sale service: We have a professional sales team and professional technical team who are willing to answer your question 24 hours on line. We can offer a set of solution for your project!

For After-sale service: We can instruct you how to use, adjust the screens, and common maintenance with spare parts.

Also, we can send engineers to your country if you need.

Q3: What’s your payment term? How long it takes to delivery?

A3: We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.

Production time would be about 15-25 days according to your order quantity.

Q4: What's the control system?

A4: For synchronous control system: We use Nova, Linsn or Colorlight control system.

For asynchronous control system: We use Onbon or Xixun control system.

Q5: How can you ensure the led display product quality?

A5: We have nearly 10-year experience in producing Led Display with good reputation in this industry.

We would do 24 hours ageing to promise 100% non-dead chips before shipment.

Fixed Install HD LED Display P10 SMD Full Color Outdoor Panel 10000 Pixel /㎡ Pixel Density

Fixed Install HD LED Display P10 SMD Full Color Outdoor Panel 10000 Pixel /㎡ Pixel Density
