Specifications
Brand Name :
Langji
Model Number :
SDC108-1
Certification :
ISO9001, ISO14001 CE, 3C, IP55
Place of Origin :
China
MOQ :
1 pc
Price :
USD 100~250/unit
Payment Terms :
T/T, Western Union, L/C,PayPal
Supply Ability :
5000 pcs / month
Delivery Time :
15~25 working days
Packaging Details :
Wooden case with pallet or just export pallet
Type :
Cabinet Air Conditioner
Condition :
Used
Mounting :
Door mount
After-sales service provided :
Online support
Operating voltage :
48V DC
Color :
RAL7035
Application :
Computer room,telecommunication,use for telecom cabinet as cooling,Telecom cabinet,Industry
Refrigerant :
R134a
Warranty :
1 Year
Cooling capacity :
800W
Description

NEMA rating 48V DC 800W outdoor telecom cabinet enclosure air Conditioning units for electrical cabinets

Product Description

Cabinet air condition is actively cooling with compressor, and it will remove the heat inside the cabinet to outside. It also can keep the dust and heat outside the cabinet, avoiding problems from using fan. The inside cabinet can be maintained at an ideal temperature for electrical components which effectively guarantees the stability of the electronic equipment and improves the reliability of the whole system.

  1. Compact structure, reasonable design and easy maintenance;
  2. Cooling capacity ranges from 300W to 5000W.
  3. Widely used for outdoor telecom cabinets, battery cabinets, electric cabinets and industry control cabinets etc.
  4. The protective level is IP55, can run at high ambient environment 55ºC.
  5. Voltage range: AC220v, 50Hz/60Hz; AC110v, 60Hz; DC-48V.
  6. Mounting: door, side and top mounted available.
  7. Digital temperature controller and high precision of temperature control.
  8. The refrigerant is R134a.The compressors are highly and panasonic.
  9. CE certified, which can meet EU RoHS requirements.

Langji DC air conditioner Technical Data Sheet

Model
SDC108-1
Cooling capacity(L35/L35)
800W
Voltage
48V DC
Power Consumption(L35/L35)
260W
Rated Current
5.4A
Circuit max pressure
26bar
Refrigerant
R134a
Working temperature
-5~55℃
Noise
60DB
IP Grade
IP55
Dimension(W×D×H)
353×165×583mm

NEMA Rating 800W Enclosure Air Conditioning Unit For Electrical Cabinets

Packing & Delivery
NEMA Rating 800W Enclosure Air Conditioning Unit For Electrical Cabinets

Company Profile

Langji Technology Co., Ltd. was founded in 2009, it is a high-tech enterprise with R&D, manufacturing and sales department. It is located at the coast of Taihu Lake Suzhou city, the registered capital is 50 million RMB. The whole factory covers 5000 square meters and employs about 200 people with an annual sale of nearly 100 million RMB.
Langji company provides full range of temperature control products and solutions for
- Telecommunication
- Data Center
- Base station
- Solar based installations
- Wireless cell sides & switches
- Industry Automation
- Energy Storage

Certification

NEMA Rating 800W Enclosure Air Conditioning Unit For Electrical Cabinets

Our Exhibition

NEMA Rating 800W Enclosure Air Conditioning Unit For Electrical Cabinets
