Specifications
Brand Name :
CE+T
Model Number :
TSI NOVA 230 VAC
Place of Origin :
CHINA
MOQ :
5
Price :
1USD
Payment Terms :
T/T
Supply Ability :
lakh
Delivery Time :
7-15days
Prat Number :
T311730102 T311730202
Brand :
CE+T
Dielectric strength DC/AC :
4300 Vdc
Nominal Output power (VA) / (W) :
750 VA / 525 W
Input voltage (DC) :
48 V
Nominal current :
12.5 A
voltage (AC*) :
220/230/240 V
Frequency :
50 - 60 Hz / 0.03 %
AC Nominal current :
3.25 A
Efficiency (Typical) :
93% / 89%
Description

CE+T TSI NOVA 48VDC 230 VAC Inverter module Power 0.75kva T311730102 T311730202

NOVA is a compact and scalable modular inverter providing a pure sine wave AC supply. In conjunction with a DC Power system, it provides an excellent AC backup solution. It uses
the latest inverter technology, providing superior energy efficiency in a compact size.
The “Twin Sine Innovation” (TSI) technology eliminates all single points of failure with full scalability; up to 32 modules in parallel and high efficiency of up to 93 % reducing operating costs.

Application

All business critical applications and all types of AC loads. The design is modular and scalable with hot- swappable inverter modules which ensures low Mean Time to Repair (MTTR), reduction in service costs and meets the changing needs for future expansion.

Specification

48 / 230
GENERAL
EMC (immunity)EN 61000-4-2 / EN 61000-4-3 / EN 61000-4-4 / EN 61000-4-5 / EN 61000-4-6 / EN 61000-4-8
EMC (emission) (class)EN 55022 (A)
SafetyEN62040-1
Cooling / IsolationForced / Doubled
MTBF200 000 hrs (MIL-217IF)
Efficiency (Typical): Enhanced power conversion / on line93% / 89%
Dielectric strength DC/AC4300 Vdc
True Redundant Systems – compliant

3 disconnection levels on AC out and DC in power ports
4 disconnection levels on AC in port

RoHSCompliant
VibrationGR63 office vibration 0 to 100 hz-0.1 g / transport vibration 5-100 Hz 0.5 g 100 to 500 hz-1.5 g / Drop test
Operating conditions

Designed for installation in an IP20 or IP21 environment.
When installed in a dusty or corrosive environment, appropriate measures (air filtering, …) must betaken.

Altitude above sea without de-rating< 1500 m / derating > 1500 m – 0.8 % per 100 m
Ambient / storage temperature / relative humidity-20 to 50 ° C / -40 to 70 ° C / 95 %, non-condensing
Material (casing)Coated steel-ALU ZINC
Nominal Output power (VA) / (W)750 VA / 525 W
Short time overload capacity135 % (15 seconds) 105 % permanent within T° range
Admissible load power factorFull power rating from 0 inductive to 0 capacitive
Internal temperature management and switch off/
DC INPUT SPECIFICATIONS
Nominal voltage (DC)48 V
Voltage range (DC)40 - 60 V
Nominal current (at 48 Vdc and 525 W output)12.5 A
Maximum input current (for 15 second) / voltage ripple22 A / < 2 mV
Input voltage boundaries/
AC INPUT SPECIFICATIONS
Nominal voltage (AC)220/230/240 V 1P or 3P (Min 3 shelves for 3P)
Voltage range (AC)150 - 265 V
Brownout150 to 185 V
438 W @ 150 Vac
Power factor> 99%
Frequency range (selectable) / synchronization range50 – 60 Hz / range 47 – 53 Hz / 57 – 63 Hz
AC OUTPUT SPECIFICATIONS
Nominal voltage (AC*)220/230/240 V
Frequency / frequency accuracy50 - 60 Hz / 0.03 %
Total harmonic distortion (resistive load)< 3 %
Load impact recovery time0.4 ms
Turn on delay20 s to 40 s depending on the number of modules installed
Nominal current3.25 A
Crest factor at nominal power2.5 : 1
With short circuit management and protection
Short circuit clear up capacity9 x In for 20 msec - Available while Mains is available at AC input port With magnitude control and management
Short circuit current after clear up capacity1.89 In
IN TRANSFER PERFORMANCE
Max. voltage interruption / total transient voltage duration (max)0 s / 0 s
SIGNALING & SUPERVISION
DisplaySynoptic LED
Alarms output / supervisionDry contacts on shelf / Use optional devices
Remote on / offOn rear terminal of the shelf via T2S ETH
