Huawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single Mode
Huawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single Mode
Huawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single Mode
Huawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single Mode
Huawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single Mode
Huawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single Mode
Specifications
Brand Name :
SOGOO
Certification :
CE, RoHS
Place of Origin :
Guangdong, China
MOQ :
10 pcs
Price :
sales@sogootech.com
Payment Terms :
T/T; Paypal; Western Union
Supply Ability :
2000 pcs per week
Delivery Time :
3-20 days depends on quantity
Packaging Details :
10pcs in 1 Anti-static package, standard packing
Model Number :
P N 14130645
Product Name :
Huawei Optical Cable P N 14130645 Parts,DLC/UPC,single mode,50m
Length :
50 m
Connector :
DLC/UPC
Insertion loss :
<=0.3 dB
Wire diameter :
7.0 mm
Cable mode :
Huawei Optical Cable single mode
Description

Huawei Optical Cable P N 14130645 Parts,DLC/UPC,single mode,50m

Huawei Optical Cable

Part Number: 14130645

Huawei Optical Cable Parts,DLC/UPC,DLC/UPC,single mode,50m,2 cores,0.03m/0.34m,GYFJH-2G.657A2,7.0mm,2mm,LSZH,Armored branch

Product Description

Fiber Optic Patch Cable is also known as fiber optic jumper or fiber optic patch cord. Fiber Optic Patch Cable is important of optical network. They have same or different connectors which are installed on the end of fiber optic cable. Fiber optic patch cables are used in two major application areas: computer work station to outlet and patch panels or optical cross connect distribution center. The Fiber Optic Patch Cord series comes with a comprehensive collection of lengths and connectors to fulfill your demand for the deployment.

Fiber optic patch cord was widely used in all kinds of optical network solutions , such as Security , WAN, LAN, CATV, FTTX, Test Equipment.

  • Screw-thread coupling mechanism
  • Ceramic ferrules
  • Low insertion loss, high return loss
  • Good in repeat ability and ex-changeability
  • 100% Insertion, Return Loss, End Face and Interference inspection
  • Excellent mechanical endurance
  • High credibility and stability

OEM Projects

Every year, we do lots of OEM items for our customers. We have vast experiences at all stages from design to prototyping approval and to mass productions. If you want to take the first chance in your market, please contact us without any hesitations.

Fiber Specification:

Fiber type
50/125,9/125
Core Diameter
50 + 2.5
Core Non-Circularity
<=5.0 %
Cladding Diameter
125.0+1.0um
Cladding Non-Circularity
<=1.0 %
Coating Diameter
245+7
Coating-Cladding Concentricity Error
<=12.0um
Coating Non-Circularity
<=6.0um

Connecton Specification
ITEM
PARAMETER
Connector type
DLC/UPC
Insertion Loss
<=0.3db
Return Loss
>=35db
Fiber mode
Multi-mode,50/125,single mode,9/125
Operating wavelength
850nm, 1300nm,1310,1550nm
Test wavelength
850nm, 1300nm
Repeatability
<=0.1
Interchangeability
<=0.2dB
Durability
<=0.2dB
Fiber Length
1m, 2m….. any length optional.
Length and tolerance
10cm
Operating Temperature
-40C ~ +85C
Storage Temperature
-40C ~ +85C
No. Huawei BOM

Type and Spec

 Length (L)
1 14130930

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-2m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 2m
2 14130931

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-5m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 5m
3 14130932

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-8m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 8m
4 14130641

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-10m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 10m
5 14131642

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-15m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 15m
6 14130642

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-20m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 20m
7 14131644

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-25m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 25m
8 14130643

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-30m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 30m
9 14131624

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-35m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 35m
10 14130644

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-40m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 40m
11 14131625

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-45m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 45m
12 14130645

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-50m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 50m
13 14131626

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-55m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 55m
14 14130646

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-60m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 60m
15 14131627

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-65m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 65m
16 14130647

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-70m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 70m
17 14132648

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-75m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 75m
18 14132649

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-80m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 80m
19 14132650

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-85m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 85m
20 14132651

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-90m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 90m
21 14132652

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-95m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 95m
22 14130648

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-100m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 100m
23 14130649

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-120m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 120m
24 14130650

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-150m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 150m
25 14130645-001

Optical cable assembly,

DLC/UPC-DLC/UPC-SM-GYFJH-2G.657A2-200m-7.0mm-2C-0.03m/0.34m-2mm-LSZH-Outdoor

 200m

Specification
Standard Duplex LC connector, well connected with standard LC adaptor
Available Single mode and Multimode
IP67 protection, salt-mist proof, humidity proof, dust proof
Low insertion/return loss, steady optical transmitting.
Light weight, waterproof, dustproof, moisture proof, Metal hard housing.

Specification

1. GYFJH Cable

1.1 Structure:

1.2 Application

Mainly used in wireless base station horizontal and vertical cabling

1.3 Features

1, Good mechanical and environmental characteristics;

2, Flame retardant characteristics meet the requirements of relevant standards;

3, The mechanical characteristics of jacket meet the requirements of relevant standards;

4, Soft, flexible, water blocked, UV resistant, easy to lay and splice, and with big capacity data transmission;

5, Meet various requirements of market and clients

1.4 Cable Parameters

Fiber Count

Cable Dimension

mm

Cable Weight

kg/km

Tensile

N

Crush

N/100mm

Min. Bend Radius

mm

Range of Temperature
Long Term Short Term Long Term Short Term Dynamic Static
2 7.0 42.3 200 400 1100 2200 20D 10D -30-+70

Note: 1. All the values in the table, which are for reference only, are subject to change without notice;

2. The cable dimension and weight are subject to the simplex cable of 2.0 outer diameter;

3. D is outer diameter of the round cable;

Huawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single ModeHuawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single ModeHuawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single Mode

Recommend Products

Huawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single Mode

Huawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single Mode

Packaging and Shipment

Huawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single Mode

Contact us

Huawei CPRI Fiber Cable P N 14130645 Parts DLC / UPC With Single Mode

Usage

Widely used in FTTA & FTTH
Used for 3G 4G base station
BBU, RRU, RRH, LTE

Packaging & Shipping

The package will be packed according to standard export requirements, customer satisfication is our target.
Label printing : Customer logo or Foclink brand are available
Inner packing: 1pcs in a plastic box
Outer packing: the carton will be packed with sack, well protect carton from dust and wet.

The transportation : By air ,by sea ,by DHL ,Fedex TNT ,UPS ...

Look forward to your inquiry on Huawei Optical Cable P N 14130645 Parts,DLC/UPC,single mode,50m.
