16MPa working pressure Heavy Duty Hydraulic Cylinder High Tonnage metallurgy
16MPa working pressure Heavy Duty Hydraulic Cylinder High Tonnage metallurgy
16MPa working pressure Heavy Duty Hydraulic Cylinder High Tonnage metallurgy
16MPa working pressure Heavy Duty Hydraulic Cylinder High Tonnage metallurgy
Specifications
Brand Name :
DALLAST
Model Number :
Customized
Certification :
ISO9001-2009 ,TS16949
Place of Origin :
shangdong
MOQ :
1PCS
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union,Paypal
Supply Ability :
3000PCS per year
Delivery Time :
20- 25 days after down payment
Packaging Details :
shrink film, pallet, plywood case and carton
Standard :
Nonstandard
Special Cylinder Type :
Piston Cylinder
Type :
YHG1
Surface Coating :
Sandblasting, Primer Paint, Middle Paint, Finish
Cylinder Case :
Carbon Steel, Alloy Steel, Stainless Steel
HS Code :
8412210000
Description

Product Features:

For metallurgy, mining equipment and other hydraulic systems

Bore Diameter:100mm
Piston Rod Diameter:55mm
Stroke:600mm



According to user requirements, design and manufacture of this series of derivative products.

Bore Diameter

(mm)

Rod Diameter

(mm)

Working pressure

16MPa

Max. Stroke

(mm)

speed

Thrust

F1(KN)

Pull F2(KN) Normal DiaConnection thread
1.4621.462
40222820.1114.0210.2510M18x1.5
50283631.4221.5615.1310M18x1.5
63364549.8833.5924.4315M27x2
80455680.4254.9840.9915M27x2
905063101.7970.3751.9115M27x2
1005670125.6686.2164.0820M33x2
1106380152.05102.1871.6320M33x2
1257090196.35134.7794.5620M33x2
14080100246.30165.88120.6425M42x2
15085105282.74191.95144.2025M42x2
16090110321.70219.91169.6525M42x2
180100125407.15281.49210.8032M48x2
200110140502.65350.60256.5332M48x2
220125160608.21411.86286.5132M48x2
250140180785.40539.10378.2540ø40
280160200985.20663.50482.5540ø40
3201802201286.80879.65678.5840ø40

16MPa working pressure Heavy Duty Hydraulic Cylinder High Tonnage metallurgy
