Sanitation Station Garbage Truck Hydraulic Cylinders 16 - 18 Mpa Working Pressure Pressure
Sanitation Station Garbage Truck Hydraulic Cylinders 16 - 18 Mpa Working Pressure Pressure
Sanitation Station Garbage Truck Hydraulic Cylinders 16 - 18 Mpa Working Pressure Pressure
Sanitation Station Garbage Truck Hydraulic Cylinders 16 - 18 Mpa Working Pressure Pressure
Sanitation Station Garbage Truck Hydraulic Cylinders 16 - 18 Mpa Working Pressure Pressure
Sanitation Station Garbage Truck Hydraulic Cylinders 16 - 18 Mpa Working Pressure Pressure
Specifications
Brand Name :
DALLAST
Model Number :
Customized
Certification :
ISO9001-2009 ,TS16949
Place of Origin :
shangdong
MOQ :
1PCS
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union,Paypal
Supply Ability :
3000PCS per year
Delivery Time :
20- 25 days after down payment
Packaging Details :
shrink film, pallet, plywood case and carton
Material :
45# steel, 27# SiMn
Color :
can custom according request
Size :
Customized
Working Pressure Pressure :
16 - 18Mpa
Warranty :
one year
Temperature :
-30ºC~100ºC
Usage :
Garbage Truck , Sanitation station
Structure :
piston cylinder
Description

Double Acting Telescopic Sanitation Station Garbage Truck Hydraulic Cylinders

Product Advantage:

Sanitation vehicles hydraulic cylinder are widely used in various types of compression sanitation garbage truck hydraulic system. This series of cylinders include push plate cylinder, sliding cylinder, scraper cylinder, lifting cylinder and so on. Push-push cylinder which is a double-acting multi-stage telescopic sleeve hydraulic cylinder, out of the oil ports are located in the rod end. The series cylinder structure is reasonable, reliable, easy assembly and disassembly, easy maintenance. Another special requirements according to user needs and technical parameters for special design.

According your request to design and manufacture .

Model Name

Pressure

MPa

Stroke

mm

Bore/Rod

mm
HSG63/35-110*470 Flip cylinder

16

 110 63(35)
HSG100/45*800 Lift cylinder(L / R) 800 100(45)
HSG90/45*485 Lift cylinder(L / R) 485 90(45)
HSG40/20-400*700 Lock pin cylinder

18

 400 40(20)
HSG80/40*430 Scraper cylinder(L / R) 18 430 80(40)
3HSTG150-1935A*1000 Multistage double action push plate cylinder

16

 1935

150/120/90

(135/105/75)
4HSTG180*5500 Multistage double action sanitation station push plate cylinder 5500

180/150/120/90

(165/135/105/75)

Sanitation Station Garbage Truck Hydraulic Cylinders 16 - 18 Mpa Working Pressure Pressure

Sanitation Station Garbage Truck Hydraulic Cylinders 16 - 18 Mpa Working Pressure Pressure

Sanitation Station Garbage Truck Hydraulic Cylinders 16 - 18 Mpa Working Pressure Pressure
