40w Motor Electric Horizontal Testing Machine Test Speed 0 ~ 300mm / Min
40w Motor Electric Horizontal Testing Machine Test Speed 0 ~ 300mm / Min
Specifications
Brand Name :
JIEDONG
Model Number :
JD-1003D
Place of Origin :
Guangdong, China
MOQ :
1
Price :
negotiate
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability :
80 sets per month
Delivery Time :
20 workdays after order confirmed
Packaging Details :
standard export plywood
Measurement selection :
50kg, 20kg, 10kg, 5kg, 2kg can be selected.
Maximum stroke (without clamp) :
250mm
Test speed :
0～300mm/min arbitrarily adjustable
weight :
15kg (about)
Operating Voltage :
220V/50HZ
Rated current :
2A
stroke :
50mm
Description

40w Motor Electric Horizontal Testing Machine Test Speed 0 ~ 300mm / Min

Electric horizontal tensile testing machine JD-1003D

product description:

The electric horizontal tensile testing machine has the advantages of wide application range, convenient use, etc., and has stepless speed regulation, manual (jog), automatic control switching function. It is suitable for the physical test test of tensile strength and insertion force of rubber, light industrial textile, composite materials, wire and cable, machinery parts and other industries.

The main technical parameters:

1. Measurement choice: 50kg, 20kg, 10kg, 5kg, 2kg can choose one.

2, the maximum stroke (without fixture): 250mm.

3, test speed: 0 ~ 300mm / min can be adjusted.

4, optional (digital display and index) push-pull force meter

5, function switch: left / stop / right / jog function

6, motor: AC frequency conversion 40W motor.

7, weight: 20kg

8, working voltage: 220V/50HZ

9, rated current: 2A

10, configuration: host, tension meter, distribution power cord, hex tools, fixtures.

40w Motor Electric Horizontal Testing Machine Test Speed 0 ~ 300mm / Min
