The Car Simulation Transport Vibration Tester Has An Amplitude Of 25.4mm

Analog Car Transport Shaking Table JD-200A

Technical Parameters:

(1) Amplitude (mm): 25.4 mm (inches);

(2) Frequency range: 100 to 300 rpm (1.5 Hz to 5 Hz);

(3) Maximum test load (kg): 200kg;

(4) Vibration mode: reciprocating type (commonly known as horse race);

(5) Work surface size: L × W (mm) 1700 × 1200;

(6) Machine top: SUS#304 stainless steel;

(7) Outer box part: baking anti-static powder spray baking table top aluminum alloy outside the electrolytic board;

(8) Time setting: 0 seconds seconds to 99 hour hours;

(9) Start time setting: 0~15seconds;

(10) Speed regulation mode: DC speed regulation;

(11) Power supply voltage (V/HZ): single phase 220V/50Hz;

(12) Environmental conditions: Temperature Temperature 5 ~ 40 ° C; Humidity ≤ 85% RH

(13) Standards: EN, ANSI, UL, ASTM, ISTA, GB/T4857.7-2005 and other domestic and international transportation standards.

Features:

(1) Digital vibrating frequency of digital instrument with vibration frequency, high precision;

(2) Synchronous silent belt drive with low noise;

(3) The sample holder is of rail type. At the same time, it is necessary to consider the need for multiple samples to be placed on top of each other for testing (with a certain height), and to configure a reusable binding tie.

(4) The base of the machine is equipped with a heavy-duty channel steel base with vibration-damping rubber. It is easy to install and runs smoothly. It does not need to install anchor screws.

(5) DC motor speed regulation, stable operation and strong load capacity;

(6) According to the reorganization of similar equipment in Europe and America, rotary vibration, in line with European and American transportation regulations.
