CM-8826 Coating Thickness Gauge Magnetic Induction F / Eddy Current N
CM-8826 Coating Thickness Gauge Magnetic Induction F / Eddy Current N
Specifications
Brand Name :
iqualitrol
Model Number :
CM-8826
MOQ :
1 Set
Payment Terms :
T/T
Supply Ability :
50 sets per month
Delivery Time :
3 Working Days
Packaging Details :
Carton Box
Principle :
NF Type Eddy Current / F Magnetic Induction
Range :
0~1250µm/0~50mil
Resolution :
0.1µm/1µm
Accuracy :
±1~3%n or ±2.5µm
Min.Radius Workpiece :
F Type:convex 1.5mm/concave 25mm/ NF Type:convex 3mm/concave 50mm
Battery Indicator :
Low Battery Indicator
Description

Magnetic Induction (F) and Eddy Current (N) Coating Thickness Gauge CM-8826

Brief Introduction:

The F probes measure the thickness of non-magnetic materials on magnetic materials. The N probes measure the thickness of non-conductive coatings on non-magnetic metals.

Features:

1, Two measuring methods: magnetic induction (F) and eddy current (N)

2, Two measurement mode: Single and Continuous(Notice:Continuous mode is convenient to measure the coating thickness of curved objects and tiny objects.)

3, Metric/imperial system selectable.

4, Manual or automatic shut down.

5, Automatic memory of calibration value,and automatic recognize the substrate.

6, Operation process have buzzing reminder,while no buzzing in continuous mode.

7, Use USB/RS-232 data output to connect with PC.

8, Provide Bluetooth data output choice.

9, Separate Type can provide several type probe, measure can be more flexibility.

Principle:

Principles Applications Examples
F Type
Magnetic Induction
(Iron Base)		 Measure the thickness of non-magnetic materials on magnetic materials Galvanizing layer, lacquer layer, porcelain enamel layer, phosphide layer, copper tile, aluminium tile, some alloy tile, paper etc
NF Type
Eddy Current
(Aluminium Base)		 Measure the thickness of non-conductive coatings on non-magnetic metals Anodizing, varnish, paint, enamel, plastic coatings, powder, etc. Applied to aluminum, brass, non-magnetic stainless steel, etc

Technical Specifications:

Principle NF Type Eddy Current / F Magnetic Induction
Range 0~1250µm/0~50mil
Resolution 0.1µm/1µm
Accuracy ±1~3%n or ±2.5µm
Min.Radius Workpiece F Type:convex 1.5mm/concave 25mm
NF Type:convex 3mm/concave 50mm
Min.Measuring Area 6mm
Min.Sample Thickness 0.3mm
Metric/Imperial Convertible
Battery Indicator Low Battery Indicator
Automatic Power Off √
Operating Conditions Temperature:0~50ºC
Humidity:<80%RH
Power Supply 4x1.5V AAA (UM-4)Battery
Dimensions 126x65x27mm
Weight 81g (Not Including Batteries)
