Specifications
Brand Name :
iqualitrol
Model Number :
QHL-602
MOQ :
1 Set
Payment Terms :
T/T
Supply Ability :
15 Sets Per Month
Delivery Time :
20 Working Days
Packaging Details :
Plywood Box
Voltage :
380V 50Hz
Temperature range :
RT(room temp)+20℃----500℃
Control System: :
Hot Air Circulation Control
Interior Dimension :
50*60*50
Material :
SUS304# Stainless Steel
Weight: :
100-200Kg
Warranty: :
1 Year
Application: :
School, Hospital, Lab, Factory
Description

150L Electric Steam Hot Air Drying Oven SUS304# Stainless Steel Material

Brief Introduction:

This drying oven can provide a stable test space for pre-heating, drying, changes about physics and chemistry testing.

Drying oven can be widely used in plastic, rubber, packaging, apparatus, machinery and metallurgy, chemical industry etc, and apply for heating of industrial and mining enterprises, scientific research units for chemical analysis physics laboratory determination and the heating treatment of general small steel parts.

Features:

●Materials: The shell is welded with high quality steel plate and the surface is treated by baking varnish. The inner case is made of mirror stainless steel #304.

●The oven adopts PID temperature controller with temperature control and digital display.It has the timing function, the temperature recovery is fast, the control temperature is accurate.

●The timer can be set in seconds, minutes, 10 minutes, hours and 10 hours, with a maximum time of 9999 hours,overtime will cut off heating, buzzer tips.

●The hot air circulation system is composed of low noise, high temperature resistant motor and special air duct design, ensuring the temperature uniformity and small fluctuation.

●Temperature range: RT(room temp)+20℃----500℃

●Heating rate:

1. RT~100℃ for about 15 minutes

2. RT~250℃ ≥3℃/min

●Over temperature protection: overload power off system

●Voltage: 380V 50Hz three-phase four-wire + protection grounding

Model Selection:

Type

Inside

dimensions

W×H×D(cm)

Outside

Dimensions

W×H×D(cm)

 Temperature range

Accu-racy

(℃)

Even-ness

(%)

 Grid Remarks
QHL-452

40×45

×40

66×82

×52

Type A: RT~250 °C

Type B: RT~300° C

Type C: RT~400° C

Type D: RT~500° C

 ±0.5 ±1.5 2 Single door
QHL-602

50×60

×50

75×116

×62

 ±0.5 ±1.5 2 Single door
QHL-802

60×100

×60

110×164

×78

 ±0.5 ±1.5 2 Single door
QHL-902

60×90

×50

83×158

×68

 ±1.0 ±1.5 2 Single door
QHL-1202

90×120

×50

109×180

×67

 ±1.0 ±1.5 2 Single door
QHL-1002

100×100

×100

120×160

×120

 ±1.0 ±1.5 4 Single door
QHL-1202L

120×90

×50

140×150

×67

 ±1.0 ±1.5 4 Dual door
QHL-1402H

140×120

×60

175×192

×78

 ±1.0 ±1.5 4 Dual door
QHL-1602

160×140

×80

200×215

×98

 ±1.0 ±1.5 4 Dual door
QHL-1802

180×140

×100

220×215

×118

 ±1.0 ±1.5 4 Dual door
QHL-2002

200×160

×120

240×235

×138

 ±1.0 ±1.5 4 Dual door

Technical Specifications:

Power AC380V, 50/60HZ, Three-phase (Specified by User)
Control System Hot air circulation control mode
Ambient temp. & humid. Range +5℃ ~ +35℃ / <85%RH
Temp. range RT+20℃~300℃(The maximum operating temperature recommend ≤260℃)
Heating up time RT~100℃within 10 min
Temp. uniformity ±1.5℃
Temp. constancy ±0.5℃
Temp. accuracy ±0.1℃
Interior material SUS304# mirror stainless steel
Exterior material high quality Cold Rolled Steel with surface treatment
Insulation Glass wool
Safety devices Overheat protector, Magnetic switch, Porcelain fuse, Alarm system
Accessories Adjustable Shelf 2pcs, Overheating protective device

Note:

1, At 20℃ ambient temperature or 25℃ water temperature and non-loaded.

2, The above specifications are for reference only, the actual specifications for the main quotation.

3, Interior dimension is available for custom made.
