Specifications
Brand Name :
iqualitrol
Model Number :
iUniv-187.5
MOQ :
1 Set
Payment Terms :
T/T
Supply Ability :
50 Sets per Month
Delivery Time :
10 Working Days
Packaging Details :
Plywood Box
Magnification :
Brinell: 37.5X, Vickers: 75X
Initial Force :
10Kgf (98N)
Dwell Time :
2~60 Seconds, Adjustable
Throat :
Max Horizontal Space 165mm
Resolution :
Rockwell: 0.5HR, Brinell: 4μm, Vickers: 2μm
Max Height :
Rockwell: 175mm, Brinell: 100mm, Vickers: 115mm
Description

Motorized Rockwell Vickers Brinell Universal Hardness Tester with Max Force 187.5Kgf

Brief Introduction:

iUniv-187.5 Brinell Rockwell & Vickers hardness tester is a multi-functional hardness tester with Brinell, Rockwell &Vickers three test modes and 7 level of test forces, which can test several kinds of hardness.

Test force loading, dwell and unloading adopts automatic system, widely application and easy to operate, therefore it is the popular machine for industrial enterprises and scientific research institutes.

Application Range:

Suitable for hardened and surface hardened steel, hard alloy steel, casting parts, non-ferrous metals, various kinds of hardening and tempering steel and tempered steel, carburized steel sheet, soft metals, surface heat treating and chemical treating materials etc.

Technical Specifications:

Model iUniv-187.5
Rockwell Test Force 60kgf (558.4N), 100kgf (980.7N), 150kgf (1471N)
Brinell Test Force 30kgf (294.2N), 31.25kgf (306.5N), 62.5kgf (612.9N), 100kgf (980.7N), 187.5kgf (1839N)
Vickers Test Force 30kgf (294.2N), 100kgf (980.7N)
Indenter

Diamond Rockwell Indenter, Diamond Vickers Indenter,

ф1.588mm, ф2.5mm, ф5mmBall Indenter
Hardness Reading Rockwell: Dial, Brinell & Vickers: Check Hardness Table
Magnification Brinell: 37.5X, Vickers: 75X
Resolution Rockwell: 0.5HR, Brinell: 4μm, Vickers: 2μm
Dwell Time 2~60s
Max. Height of Specimen Rockwell: 175mm, Brinell: 100mm, Vickers: 115mm
Throat 165mm
Power Supply AC220V/50Hz/1Ph, AC110V/60Hz/1Ph
Execute Standard

ISO 6508, ASTM E-18, JIS Z2245, GB/T 230.2

ISO 6506, ASTM E10-12, JIS Z2243, GB/T 231.2

ISO 6507, ASTM E92, JIS Z2244, GB/T 4340.2
Dimension 520×240×700mm, Packing Dimension: 650×370×950mm
Weight Net Weight: 80kg, Gross Weight: 105kg

Packing List:

Name Qty Name Qty
Instrument Main Body 1 set Diamond Rockwell Indenter 1 pc
Diamond Vickers Indenter 1 pc ф1.588mm, ф2.5mm, ф5mmBall Indenter each 1 pc
Slipped Test Table 1 pc Middle Plane Test Table 1 pc
Large Plane Test Table 1 pc V-shaped Test Table 1 pc
15x Digital Measuring Eyepiece 1 pc 2.5x, 5x Objective each 1 pc
Microscope System (include the inside light and outside light) 1 set Hardness Block 150~250 HBW 2.5/187.5 1 pc
Hardness Block 60~70 HRC 1 pc Hardness Block 20~30 HRC 1 pc
Hardness Block 80~100 HRB 1 pc Hardness Block 700~800 HV30 1 pc
Weights 0, 1, 2, 3, 4 5 pcs Power Cable 1 pc
Fuse 2A 2 pcs Horizontal Regulating Screw 4 pcs
Level 1 pc Spanner 1 pc
Screw Driver 1 pc Anti-dust Cover 1 pc
Usage Instruction Manual 1 copy

The diamond penetrator is used for testing materials such as hardened steels and cemented carbides. The carbide ball penetrators, available with 1/16 inch, 1/8 inch, 1/4 inch, and 1/2 inch diameter, are used when testing materials such as steel-copper alloys, aluminum and plastics to name a few.

Rockwell testing falls into two categories: Regular Rockwell testing (e.g., C and B scales) and Rockwell superficial testing (e.g., 30 N and 30 T scales).

High Rockwell hardness numbers represent hard materials and low numbers soft materials.
