Resolution 0.1HR Touch Screen Digital Rockwell Hardness Tester with Built-in Printer
Resolution 0.1HR Touch Screen Digital Rockwell Hardness Tester with Built-in Printer
Resolution 0.1HR Touch Screen Digital Rockwell Hardness Tester with Built-in Printer
Resolution 0.1HR Touch Screen Digital Rockwell Hardness Tester with Built-in Printer
Resolution 0.1HR Touch Screen Digital Rockwell Hardness Tester with Built-in Printer
Resolution 0.1HR Touch Screen Digital Rockwell Hardness Tester with Built-in Printer
Resolution 0.1HR Touch Screen Digital Rockwell Hardness Tester with Built-in Printer
Resolution 0.1HR Touch Screen Digital Rockwell Hardness Tester with Built-in Printer
Specifications
Brand Name :
iqualitrol
Model Number :
iRock-432T
MOQ :
1 Set
Payment Terms :
T/T
Supply Ability :
20 Sets per Month
Delivery Time :
10 Working Days
Packaging Details :
Plywood Box
Initial Force :
10kgf (98.07N)
HRC Indenter :
Diamond Rockwell Indenter
Loading Control :
Automatic (Loading/Dwell/Unloading)
Vertical Space :
175mm
Hardness Reading :
Touch Screen Display
Horizontal Space :
165mm
Description

Resolution 0.1HR Touch Screen Digital Rockwell Hardness Tester with Built-in Printer


Model: iRock-432T

Technical Specifications:

Model iRock-432T
Initial Test Force 10kgf (98.07N)
Total Test Force 60kgf (558.4N), 100kgf (980.7N), 150kgf (1471N)
Indenter Diamond Rockwell Indenter, ф1.588mmBall Indenter
Loading Method Automatic (Loading/Dwell/Unloading)
Hardness Reading Touch Screen Display
Test Scale HRA, HRD, HRC, HRF, HRB, HRG, HRH, HRE, HRK, HRL, HRM, HRP, HRR, HRS, HRV
Conversion Scale HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS, HBW
Data Output Built-in Printer, RS232 Interface
Resolution 0.1HR
Dwell Time 0~60s
Max. Height of Specimen 175mm
Throat 165mm
Power Supply AC220V, 50Hz
Execute Standard ISO 6508, ASTM E-18, JIS Z2245, GB/T 230.2
Dimension 520×215×700mm, Packing Dimension: 650×370×950mm
Weight Net Weight: 78kg, Gross Weight: 100kg

iqualitrol iRock-432T Digital Rockwell hardness tester adopts the high resolution color touch screen with high brightness display.


iRock-432T can show and set the present scale, test force, test indenter, dwell time and hardness conversion.

Main Functions:
Support all the Rockwell scales;
With hardness conversion among all metal hardness scales;

Adjustable back light with energy-saving mode;
Real time data saving in the folder, totally six folders, the data can be arbitrary copied, cut, deleted, pasted;

the hardness scale, data range and the remarks can be selective displayed, similar to Excel function;
Test results can be saved in real time and can be selective checked and printed out, automatic calculation of maximum, minimum and average value;

Increase the operation process interface, easy to use; With RS232 interface for connecting to the computer.

Application Range:
Suitable for quenched steel, tempered steel, annealed steel, cold and hard casting, malleable cast iron, hard alloy steel, aluminum alloy, copper alloy, bearing steel etc.


Packing List:

Name Qty Name Qty
Instrument Main Body 1 set Diamond Rockwell Indenter 1 pc
ф1.588mmBall Indenter 1 pc Middle Plane Test Table 1 pc
Large Plane Test Table 1 pc V-shaped Test Table 1 pc
Hardness Block 60~70 HRC 1 pc Hardness Block 20~30 HRC 1 pc
Hardness Block 80~100 HRB 1 pc Weight A, B, C 3 pcs
Power Cable 1 pc Fuse 2A 2 pcs
Level 1 pc Horizontal Regulating Screw 4 pcs
Screw Driver 1 pc Spanner 1 pc
Anti-dust Cover 1 pc Usage Instruction Manual 1 copy
