Digital Readout DP300 Halogen Illumination 600mm Screen Horizontal Profile Projector with Printer
Digital Readout DP300 Halogen Illumination 600mm Screen Horizontal Profile Projector with Printer
Digital Readout DP300 Halogen Illumination 600mm Screen Horizontal Profile Projector with Printer
Digital Readout DP300 Halogen Illumination 600mm Screen Horizontal Profile Projector with Printer
Specifications
Brand Name :
iqualitrol
Model Number :
HB24-3015
MOQ :
1 set
Payment Terms :
T/T
Supply Ability :
20 Sets per Month
Delivery Time :
10 Working Days
Packaging Details :
Plywood Box
Travel :
X-Z 300x150mm
Screen :
Effective Range ≥ Ø600
Resolution :
X-Z 0.0005mm
Accuracy :
≤3+L/200(um)
Description

Horizontal Optical Profile Projector HB24-3015 With 600mm Screen And Digital Readout DP300

Key Features:

1, 600mm diameter screen with digital protractor;

2, 300x150mm precision movement work-stage, 300x200mm optional;

3, Work-stage sway range between ±15°;

4, Halogen profile and fiber surface illumination adjustable;

5, Geometric multifunction data processing system DRO DP300;

6, Built-in Mini-printer;

7, Available 10x,20x objective rotary table, working cupboard and foot-switch, etc.

Technical Specifications:

Model HB24-3015
Metal Stage Size 455x126mm
Stage Travel: X and Z-axis 300x150mm
Stage Travel:Y-axis 75mm (for focusing)
X and Z Linear Resolution 0.0005mm
Sway Range ±15°
Accuracy ≤3+L/200(um)
Screen

Diameter :Ø625mm,Effective Range ≥ Ø600

(with “* ” Reticle)

Rotary Range: 0~360° ;

Resolution Rotary Indicator: 1’ or 0.01°
Digital Readout DP 300 Multifunctional Data Processing System
Illumination Contour illumination:24v/150w (halogen Lamp )
Surface illumination:21v/150w (Optical Fiber)
Power Supply AC110V/60Hz; 220V/50Hz,650w
Dimension (D×W×H) 1620x750x1400mm
Packing Dimension (L×W×H) 1790x890x1520mm
Instrument Gross/Net Weight 300/250kg

Standard Delivery:

Digital Readout DP300 10x Objective Screen Clamp Device
Built-in Mini-printer Power Cable Operation Manual

Optional Accessories:

Measuring Software Working Cupboard Standard Block Rotary Vise
20x Objective 50X Objective Over-Chart Printing Paper
Holder Clamp V-shape Clamp Swivel Center Support Foot-Switch
