Temperature And Humidity Environmental Test Chamber With CE ISO SGS Certification
Temperature And Humidity Environmental Test Chamber With CE ISO SGS Certification
Temperature And Humidity Environmental Test Chamber With CE ISO SGS Certification
Temperature And Humidity Environmental Test Chamber With CE ISO SGS Certification
Temperature And Humidity Environmental Test Chamber With CE ISO SGS Certification
Temperature And Humidity Environmental Test Chamber With CE ISO SGS Certification
Temperature And Humidity Environmental Test Chamber With CE ISO SGS Certification
Temperature And Humidity Environmental Test Chamber With CE ISO SGS Certification
Temperature And Humidity Environmental Test Chamber With CE ISO SGS Certification
Temperature And Humidity Environmental Test Chamber With CE ISO SGS Certification
Specifications
Brand Name :
iqualitrol
Model Number :
QTH-1000B
MOQ :
1 SET
Payment Terms :
T/T
Supply Ability :
15 Sets per Month
Delivery Time :
30 Working Days
Packaging Details :
Plywood Box
Temperature :
range -20~150C
Power :
220V or 380V 50/60Hz
Usage :
Temperature Humidity Test Chamber for Resisting Heat
Humidity range :
20%~98%
Controller :
Programmable LCD touch screen
Warranty :
1 Year
Test Hole :
Diameter 50mm
Inside material :
Stainless steel SUS 304 #
Description

Alternate Temperature and Humidity Environmental Test Chamber Series with CE, ISO, SGS Certification

Scope of Application:
This equipment is suitable for various types of electrical and electronic products and other product, components and parts and materials to high and low temperature constant and gradual change, humidity and heat test Environmental simulation reliability test; Other uses May cause injury to personnel and damage to machinery and equipment.

Test Limit:
1. Inflammable,explode, effumability test and storage of material samples
2. Corrosive material sample test and storage biological sample test or storage.
3. Strong electromagnetic emission source specimen test and storage.

Testing Standards:
1. GB/T2423.1-2001 test A: Low temperature (part)
2. GB/T2423.2-2001 test B: high temperature (part)
3. GB/T2423.3-2006 test Cab : Steady damp-heat
4. GB/T2423.4-1993 test Db: Alternating humid heat
5. GB/T2423.34-2005 test Z/AD: Temperature and humidity combination
6. QC/T413-2002 medium product temperature resistance/humidity cycling performance
7. GB/T2423.3,4 requirements for the heat and humid heat cycle of the medium steady state
8. GB/T5170.2-2008 electric and electronic products environmental testing equipment method temperature test equipment
9. GB/T5170.5-2008 electric and electronic products environmental testing equipment method hygrothermal test equipment.

Model Selection:

Model Temp and Humidity
Range		 Internal Dimension
(W x H x D) cm		 Exterior Dimension
(W x H x D) cm
QTH-100A

A=0℃～﹢150℃

B=-20℃～﹢150℃

C=-40℃～﹢150℃

D=-70℃～﹢150℃

20%～98%RH

 50x50x40 75x120x115
QTH-100B
QTH-100C
QTH-100D
QTH-150A

50x60x50

75x130x125
QTH-150B
QTH-150C
QTH-150D
QTH-225A

50x75x60

75x145x135
QTH-225B
QTH-225C
QTH-225D
QTH-416A 70x85x70 95x185x145
QTH-416B
QTH-416C
QTH-416D
QTH-1000A 100x100x100 125x195x165
QTH-1000B
QTH-1000C
QTH-1000D
Remark: 20%～98%RH is standard humidity range, support custom made 5%～98%RH
Support custom made dimension

Technical Specifications:

Control Mode Balanced Temperature and Humidity Control System
Operating Temp. & Humid. +5℃ ~ +35℃; <85%R.H.
Temp. range A=0℃,B=-20℃, C=-40℃, D=-70℃ ~ +100℃(150℃)
Humid. range 20% ~98%R.H.
(Optional: 5%~98%R.H.)
Temp. & Humid. fluctuation ±0.5deg; ±2.5%R.H.
Temp. & Humid. uniformity ≤2.0deg; ≤3%R.H.
Temp. & Humid. Deviation ≤1.0deg; ≤2%R.H.
Temp. Heating Time 0℃ ~ +100℃ within 30min; -20℃ ~ +150℃ within 45min
Temp. Cooling Time 20℃~ -40℃ within 60min; 20℃ ~ -70℃ within 85min
Power Supply AC 380V, 50/60 HZ, three-phase (specified by user)
Exterior Material Stainless steel with baking paint
Interior material SUS 304# stainless steel
Insulation material Rigid Polyurethane Foam
Refrigeration system Mechanical cascade refrigeration system; fin type radiator
Circulation system Mechanical convection system
Humidification Water Supply

Automatic water regulating, recoverable supply system,

water shortage alarm system
Water quality Distilled water only, 20L Water tank capacity
Controller Touch Screen Controller
Safety devices Overheat protector Switch, compressor overload protector switch,
water shortage protector switch, humidifier protector Switch,
Fault alarm system
Accessories Viewing window, Chamber Illumination, Cable port ø50mm,
Product shelf slides 2 pieces, universal casters
Touch screen controller
